Annealing of Aluminum Implanted 4H-SiC: Comparison of Furnace and Lamp Annealing

Abstract:

Furnace annealing and lamp annealing of aluminum implanted layers in 4H silicon carbide (SiC) were investigated with respect to surface degradation and electrical parameters. A sheet resistance of about 20kW/ı was obtained for an aluminum implantation dose of 1.2×1015cm-2 and annealing in the furnace at 1700°C for 30min. For the same implantation dose, lamp annealing at 1770°C for 5min resulted in a three times higher sheet resistance of 60kW/ı. The surface roughness was best for the lamp system and stayed below 1nm for Al doses lower than 1×1015cm-2.

You might also be interested in these eBooks

Silicon Carbide and Related Materials 2004

View Preview

Info:

Periodical:

Materials Science Forum (Volumes 483-485)

Pages:

621-624

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.483-485.621

Citation:

Cite this paper

Online since:

May 2005

Authors:

Martin Rambach, Anton J. Bauer, Lothar Frey, Peter Friedrichs, Heiner Ryssel

Keywords:

Annealing, Ion Implantation, Sheet Resistance, Surface Roughness (SR)

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] T. Troffer, M. Schadt, T. Frank, H. Itoh, G. Pensl, J. Heindl, H.P. Strunk and M. Maier: phys. stat. sol (a) Vol. 162 (1997), p.277.

DOI: 10.1002/1521-396x(199707)162:1<277::aid-pssa277>3.0.co;2-c

Google Scholar

[2] H. Wirth, D. Pankin, W. Skorupa and E. Niemann: Appl. Phys. Lett. Vol. 74 (7) (1999), p.979.

Google Scholar

[3] M. Capano, S. Ryu, J. Cooper jr. M. Melloch, K. Rottner, S. Karlsson, N. Nordell, A. Powell and D. Walker jr.: Jour. Electr. Mat. Vol. 28 (3) (1999), p.214.

DOI: 10.1007/s11664-999-0016-z

Google Scholar

[4] W. Weber, W. Jiang and S. Thevuthasan: Nucl. Instrum. Methods B Vol. 175-177 (2001), p.26.

Google Scholar

[5] M. Lazar, C. Raynaud, D. Planson, J. -P. Chante, M. -L. Locatelli, L. Ottaviani and P. Godingnon: Jour. Appl. Phys. Vol. 94 (5) (2003), p.2992.

Google Scholar
