Numerical Modeling of Residual Stress and Prediction of Heat Affected Zone Induced by PTA Process

Abstract:

The objective of this study is to investigate the effects of Heat Affected Zone produced by Plasma Transferred Arc process and residual stress in substrate steel 55NiCrMoV7. In this study, based on ABAQUS code, a sequentially coupled thermal, metallurgical, mechanical 2-D finite element model is developed. In the numerical simulations, the coating and Heat Affected Zone are used to predict the residual stresses. The simulation results revealed that the final residual stress in substrate steel do seem to be influenced by the HAZ.
