Generalized Pole Figures and Stored Energy Distribution Function Obtained by X-Ray Diffraction

Abstract:

Abstract. Anisotropy of physical and mechanical properties of textured polycrystalline materials strongly depends on microstructural characteristics, such as subgrain sizes, lattice deformations, etc. Generalized Pole Figures (GPF) are an attempt to estimate the anisotropy of these properties; so, the energy stored during plastic deformation is a key parameter in primary recrystallization. In this work, the technique to measure GPF (measurements and software) was implemented for X-Ray diffraction and applied to study of property anisotropy of a Fe50%Ni alloy. GPF’s of texture, crystallite size, stored energy and diffraction peak shift, (among others) have been characterized. The Full Width at Half Maximum (FWHM) of obtained instrumental functions shows that defocusing is significant for polar angle higher than 50°. The mixing parameter of the pseudo-Voigt function using in fitting, presents important dispersions.

• Periodical: Materials Science Forum (Volumes 702-703)
• Pages: 519-522
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.702-703.519
• Online since: December 2011
• Authors: Francisco Cruz-Gandarilla, A.M. Salcedo-Garrido, Thierry Baudin, H. Mendoza-León, Richard Penelle
• Keywords: Anisotropy, Generalized Pole Figure, Microstructure, Store Energy Distribution Function, Texture

References

[1] Y. Perlovich, H.J. Bunge and M. Isaenkova. Inhomogeneous Distribution of Residual Deformation Effects in Textured BCC Metals. Textures & Microstructures, 29 (1997) 241-266.

DOI: 10.1155/tsm.29.241

[2] D. Chateigner, Combined Analysis: Structure-texture microstructure-phase-stresses-reflectivity determination by x-ray and neutron scattering, Wiley-ISTE, (2010).

[3] R.A. Young, The Rietveld Method. Edit. IUCr Oxford University Press (1993).

[4] J.S. Kallend and Y.C. Huang, Orientation dependence of stored energy of cold work in 50% cold rolled copper, Metal Science 18 (1984) 381-385.

DOI: 10.1179/030634584790419890

[5] H.J. Bunge, Texture Analysis in Materials Science. Mathematical Methods,. Ed Butterworths (1982). ISSN 0-408-10642-5.

[6] V. Branger, M.H. Mathon, T. Baudin, and R. Penelle, Neutron Diffraction Study of Stored Energy in the Cold Rolled Fe 53%-Ni Alloy in Proceedings of the 21 st Risø International Symposium on Materials Science. Ed. N. Hansen, X. Huang, D. Juul Jensen, E.M. Lauridsen, T. Leffers, W. Pantleon, T.J. Sabin and J.A. Wert. Denmark (2000).

DOI: 10.1016/s1359-6462(01)01245-3

[7] N. Rajmohan, Y. Hayakawa, J.A. Szpunar and J.H. Root, The determination of orientation-dependent stored energy using neutron diffraction. Physica B 241-243 (1998) 1225-1227.

DOI: 10.1016/s0921-4526(97)00834-x

[8] T. Baudin, D. Solas, A.L. Etter, D. Ceccaldi and R. Penelle, Simulation of primary recrystallization from TEM observations and neutron diffraction measurements, Scripta Materialia, 51 (5), 427-430 (2004).

DOI: 10.1016/j.scriptamat.2004.05.001

[9] R. Penelle and T. Baudin, Primary Recrystallization of Invar, Fe-36%Ni Alloy: Origin and Development of the Cubic Texture Advanced Engineering Materials 12-10 (2010) 1047–1052.

DOI: 10.1002/adem.201000077

[10] J. Rodríguez-Carvajal, Information on http: /www. ill. eu/sites/fullprof/php/tutorials. html. Documents about microstructure. Study of Micro-Structural Effects by Powder Diffraction Using the Program FULLPROF.

[11] J.I. Langford, R. Delhez, Th.H. de Keijser and E. Mittemeijer, Profile Analysis for Microcrystalline Properties by the Fourier and Other Methods, Aust. J. Phys., 41, (1988) 173-187.

DOI: 10.1071/ph880173

[12] Th. H. de Keijser, J.I. Langford, E.J. Mittemeije and. A. B. P. Vogels, Use of the Voigt Function in a Single-Line Method for the Analysis of X-ray Diffraction Line Broadening, J. Appl. Cryst. 15 (1982) 308-314.

DOI: 10.1107/s0021889882012035

[13] G. R. Stibitz, Energy and Lattice spacing in strained solids, Phys Rev 49 (1937) 872.

[14] M. Ceretti and A. Lodini, « Analyse des Contraintes Résiduelles par Diffraction de Rayons X et des Neutrons » . Editeurs Alain Lodini et Michel Perrin. Évaluation des Contraintes Résiduelles à partir de la Mesure des Microdéformations dans les Matériaux Polycristallins. Ed. Commissariat à l'Énergie Atomique. France (1994).

DOI: 10.1051/978-2-7598-0863-2.c007

[15] H. Landolt and R. Börnstein , New Series III/29a (Ed by D. F. Nelson) 1. 2. 1 Elastic constants Sρ, σ, Cρ, σ. Cubic system Alloys, Table 4, p.29 Springer Verlag, Berlin. SpringerMaterials - The Landolt-Börnstein Database. (1992).

DOI: 10.1007/10046537_38

[16] Information on http: /esfm. ipn. mx/~fcruz/FPG-SEDF. zip.

[17] K. Pawlik, and P. Ozga, LaboTex: The Texture Analysis Software,. Information on http: /www. labosoft. com. pl/index. htm.
