Rapid Imaging of Carrier Density of Si Using Reflectance Measurement in the Terahertz Region

Abstract:

Rapid imaging of the carrier density of n-type silicon (Si) was carried out at the rate of 2 s per point using a terahertz wave of 4.4 THz generated from a tunable terahertz source. Reflectance of 4.4 THz as a function of carrier density was calculated using a simple Drude model. The carrier densities obtained from the terahertz imaging were 1 × 10¹⁸ cm⁻³ and 3 × 10¹⁸ cm⁻³, respectively.
