Evaluation of the Drive Circuit for a Dual Gate Trench SiC JFET

Abstract:

The paper discusses the switching performance of the double-gate SiC trench JFET. In applications such as dc/dc converters, when fast switching is expected the standard totem-pole driver is not sufficient. The reason for this is that both the internal resistance and the parasitic capacitances of this device are significantly higher than for other designs. Instead, the gate driver with a dynamic current source is proposed in this paper to speed-up the switching process. Performed double-pulse measurements show improved dynamic performance of the tested DGTJFET with the new driver.

• Periodical: Materials Science Forum (Volumes 740-742)
• Pages: 946-949
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.740-742.946
• Online since: January 2013
• Authors: Jacek Rabkowski, Dimosthenis Peftitsis, Mietek Bakowski, Hans Peter Nee
• Keywords: Current-Source, Dual-Gate Trench (DGT) JFET, Gate Driver, SiC JFET, Switching Performance

References

[1] Biela, J., Schweizer, M., Waffler, S., Kolar, J. W.; SiC vs. Si - Evaluation of Potentials for Performance Improvement of Inverter and DC-DC Converter Systems by SiC Power Semiconductors, IEEE Transactions on Industrial Electronics, Vol.: 57 , Iss. 7, pp.2872-2882 (2011).

DOI: 10.1109/tie.2010.2072896

[2] D. Peftitsis, J. Rabkowski, G. Tolstoy, H. -P. Nee, Experimental comparison of dc/dc boost converters with SiC JFETs and SiC bipolar transistors, European Conference on Power Electronics and Applications, EPE'(2011).

DOI: 10.1109/icpe.2011.5944660

[3] J. Rabkowski, D. Peftitsis, H. -P. Nee, SiC power transistors – a new era in power electronics is initiated, IEEE Industrial Electronics Magazine, vol. 6, Issue 2, 2012, pp.17-26.

DOI: 10.1109/mie.2012.2193291

[4] http: /www. cree. com/power/products/z-fet-sic-mosfet.

[5] http: /semisouth. com/power-semiconductors/sic-transistors.

[6] http: /www. transic. com/index. php/products.

[7] The Industry's First SiC Power MOSFET with Internal SiC SBD (at www. rohm. com).

[8] ] R. K. Malhan, Y. Takeuchi, M. Kataoka, A. -P. Mihaila, S.J. Rashid, F. Udrea and G.A.J. Amaratunga, Microelectronics Engineering 83, 107 (2006).

DOI: 10.1016/j.mee.2005.10.035

[9] R. K. Malhan, M. Bakowski, Y. Takeuchi; N. Sugiyama; A. Schöner; Design, process, and performance of all-epitaxial normally-off SiC JFETs, Phys. Status Solidi A 206, No. 10, pp.2308-2328 (2009).

DOI: 10.1002/pssa.200925254

[10] J. Rabkowski, M. Zdanowski, D. Peftitsis, H. -P. Nee, A Simple High-Performance Low-Loss Current-Source Driver for SiC Bipolar Transistors, 7th International Power Electronics and Motion Control Conference - ECCE Asia June 2-5, 2012, Harbin, China.

DOI: 10.1109/ipemc.2012.6258834
