Experimental Study of Short-Circuit Capability of Normally-off SiC-BGSITs

Abstract:

We investigated the short-circuit capabilities of 1.2 kV normally-off SiC buried gate static induction transistors (SiC-BGSITs). The maximum short-circuit energy was found to be 35.6 J/cm2, which is twice that of normally-on SiC-BGSITs and 3.3–5.6 times higher than that of the Si-IGBTs. The maximum short-circuit time was 590 μs. It is concluded that these high short-circuit capabilities result from saturation characteristics of the normally-off SiC-BGSITs.

• Periodical: Materials Science Forum (Volumes 740-742)
• Pages: 962-965
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.740-742.962
• Online since: January 2013
• Authors: Akio Takatsuka, Yasunori Tanaka, Koji Yano, Tsutomu Yatsuo, Kazuo Arai
• Keywords: Buried Gate Static Induction Transistor, Normally-Off, Short-Circuit Capability, Silicon Carbide (SiC)

References

[1] Y. Tanaka, M. Okamoto, A. Takatsuka, K. Arai, T. Yatsuo, K. Yano, and M. Kasuga: IEEE Electron Device Lett. 27 (2006) 908.

DOI: 10.1109/led.2006.884724

[2] A. Takatsuka, Y. Tanaka, T. Yatsuo, and K. Arai: Mater. Sci. Forum 679-680 (2011) 662.

[3] K. Yano, Y. Tanaka, T. Yatsuo, A. Takatsuka, and K. Akai: IEEE Trans. Electron Devices, vol. 57, No. 4, pp.919-927, Apr. (2010).

[4] Y. Nakao, S. Watanabe, N. Miura, M. Imaizumi and T. Oomori: Mater. Sci. Forum 600-603 (2009) 1123.

[5] M. Otsuki, Y. Onozawa, H. Kanemaru, Y. Seki and T. Matsumoto: IEEE Trans. Electron Devices, vol. 50, No. 6, pp.1525-1531, Jun. (2003).

DOI: 10.1109/ted.2003.813505

[6] S. Lefebvre, Z. Khatir, and F. Saint-Eve: IEEE Trans. Electron Devices, vol. 52, No. 2, pp.276-283, Feb. (2005).

DOI: 10.1109/ted.2004.842714
