The Alloying and Aging Effects on the Wettability and Intermetallic Bonding of the Sn-Zn-Cu-Bi Soldering Alloy on a Cu Substrate

Abstract:

The soldered bonding between the Sn-Zn-Cu-Bi system and a Cu substrate was studied and reported herein. The alloying compositions were varied to investigate the effects of Zn, Cu, Bi contents on the solders’ melting temperature (T_m), microstructures, wettability and the intermetallic-compound (IMC) bonding with a Cu substrate. The Sn-7Zn and Sn-9Zn exhibited low T_m (198 °C), but poor wettability on the Cu substrates. Both Cu and Bi additions significantly improved the solder wettability. However, the T_m of the Sn-Zn-Cu series increased sharply to about 225 °C by the addition of 4-wt% Cu. The addition of 3-wt% Bi lowered T_m of the Sn-Zn-Cu alloys by 5 °C. The thickness of the IMC layers between solder and substrate was maximum for Sn-9Zn and significantly decreased with the Cu addition. With the addition of Bi to Sn-Zn-Cu, the IMC thickness increased. The aging of 150 °C for 150 hours minimally affected the IMC-bonding thicknesses of most samples; however, micro crack could be observed along the aged IMC layers.

• Periodical: Materials Science Forum (Volume 857)
• Pages: 26-30
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.857.26
• Online since: May 2016
• Authors: Surakan Sunyadeth, Pun Wirot, Boonrat Lohwongwatana, Ratchatee Techapiesancharoenkij*
• Keywords: Aging Effect, Intermetallic Compounds, Sn-Zn-Cu-Bi Lead-Free Solder, Wetting Angle

References

[1] X. Wei, H. Huang, L. Zhou, M. Zhang and X. Liu: Materials Letter. Vol. 61 (2007), p.655.

[2] T.C. Chang, S.M. Chou, M.H. Hon and M.C. Wang: Materials Science and Engineering A. Vol. 429 (2006), p.36.

[3] Y. Min, L. Xiuzhong, L. Xinghong and D. Jiahui in: Proceedings on 11th International Conference on Electronic Packaging Technology & High Density Packaging (2010), p.784.

DOI: 10.1109/icept.2010.5582695

[4] D.Q. Yu, H.P. Xie, and L. Wang: Journal of Alloys and Compound. Vol. 385 (2004), p.119.

[5] W. Terdthaichairat, P. Senthongkaew and R. Techapiesancharoenkij: Key Engineering Materials. Vol. 658 (2015), p.59.

[6] J.E. Lee: Journal of Alloys and Compounds. Vol. 454 (2008), p.310.

[7] L. Xiuzhong, Y. Min , L. Xinghong and D. Jiahui in: Proceedings on 11th International Conference on Electronic Packaging Technology & High Density Packaging (2010), p.789.

DOI: 10.1109/icept.2010.5582695

[8] M. Abtewa and G. Selvaduray: Materials Science and Engineering. Vol. 27 (2000), p.95.

[9] R. Mayappan, R.A. Zaman, Z Zalina, Abidin, A.F. Alias and M.N. Derman: Advanced Materials Research. Vol. 173 (2011), p.90.
