Study of In-Plane Orientation of Epitaxial Si Films Grown on 6H-SiC(0001)

Abstract:

The Si/SiC heterojunctions were prepared on 6H-SiC(0001) by low-pressure chemical vapour deposition at 900°C. X-ray diffraction was employed to investigate the in-plane orientation of Si/SiC heterojunctions. A FCC-on-HCP parallel epitaxy was achieved for the Si(111)/SiC(0001) heterostructure with a growth temperature of 900°C and the in-plane orientation relationship was [01-1]_Si//[11-20]_6H-SiC. Based on the in-plane orientation characterizations, the lattice-structure model of the Si/6H-SiC heterostructure was constructed. It is shown that when the in-plane orientation was (111)[01-1]_Si//(0001)[11-20]_6H-SiC, the Si/6H-SiC interface had a 4:5 Si-to-SiC matching mode with a residual lattice-mismatch of 0.26%, and the misfit dislocation density at the Si/SiC interface was calculated as 0.487×10¹⁴cm^-2.

• Periodical: Materials Science Forum (Volume 858)
• Pages: 221-224
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.858.221
• Online since: May 2016
• Authors: Lian Bi Li*, Zhi Ming Chen
• Keywords: Epitaxial Growth, In-Plane Orientation, Si/6H-SiC Heterostructure, XRD Phi Scan

References

[1] J.P. Henning, K.J. Schoen, M.R. Melloch, J.M. Woodall, J.A. Cooper, Electrical Characteristics of Rectifying Polycrystalline Silicon/Silicon Carbide Heterojunctions, J. Electron. Mater. 27 (1998) 296-299.

DOI: 10.1007/s11664-998-0403-x

[2] J.F. Seely, B. Kjornrattanawanich, G.E. Holland, R. Korde, Response of a SiC Photodiode to Extreme Ultraviolet through Visible Radiation, Opt. Lett. 30 (2005) 3120-3122.

DOI: 10.1364/ol.30.003120

[3] X. Xin, F. Yan, T.W. Koeth, C. Joseph, J. Hu, J. Wu, J.H. Zhao, Demonstration of 4H-SiC Visible-blind EUV and UV Detector with Large Detection Area, Electron. Lett. 41 (2005) 1192-1193.

DOI: 10.1049/el:20052977

[4] J. Hu, X. Xin, J.H. Zhao, F. Yan, B. Guan, J. Seely, B. Kjornrattanawanich, Highly Sensitive Visible-blind Extreme Ultraviolet Ni/4H-SiC Schottky Photodiodes with Large Detection Area, Opt. Lett. 31 (2006) 1591-1593.

DOI: 10.1364/ol.31.001591

[5] L.B. Li, Z.M. Chen, Z.Q. Ren, Z.J. Gao, Non-UV Photoelectric Properties of the Ni/n-Si/N+-SiC Isotype Heterostructure Schottky Barrier Photodiode. Chin. Phys. lett. 30 (2013) 097304.

DOI: 10.1088/0256-307x/30/9/097304

[6] L.B. Li, Z.M. Chen, W.T. Liu, W.C. Li, Electrical and photoelectric properties of p-Si/n+-6H-SiC heterojunction non-ultraviolet photodiode, Electron. Lett. 48 (2012) 1227-1228.

DOI: 10.1049/el.2012.1471

[7] H. Tetsuya, T. Hideaki, S. Yoshio, T. Satoshi, H. Masakatsu, New High-Voltage Unipolar Mode p+-Si/n-4H-SiC Heterojunction Diode, Mater. Sci. Forum 483-485 (2005) 953-956.

DOI: 10.4028/www.scientific.net/msf.483-485.953

[8] A. Pérez-Tomás, M.R. Jennings, M. Davis, J.A. Covington, P.A. Mawby, V. Shah, T. Grasby, Characterization and Modeling of n-n Si/SiC Heterojunction Diodes, J. Appl. Phys. 102 (2007) 014505.

DOI: 10.1063/1.2752148

[9] A. Pérez-Tomás, M.R. Jennings, M. Davis, V. Shah, T. Grasby, J.A. Covington, P.A. Mawby, High doped MBE Si p-n and n-n heterojunction diodes on 4H-SiC, Microelectron. J. 38 (2007) 1233-1237.

DOI: 10.1016/j.mejo.2007.09.019

[10] O.J. Guy, T.E. Jenkins, M. Lodzinski, A. Castaing, S.P. Wilks, P. Bailey, T.C.Q. Noakes, Ellipsometric and MEIS Studies of 4H-SiC/Si/SiO2 and 4H-SiC/SiO2 Interfaces for MOS Devices, Mater. Sci. Forum 556-557 (2007) 509-512.

DOI: 10.4028/www.scientific.net/msf.556-557.509

[11] L.F. Xie, Z.M. Chen, L.B. Li, C. Yang, X.M. He, N. Ye, Preferential Growth of Si Films on 6H-SiC(0001) C-face, Appl. Surf. Sci. 261 (2012) 88-91.

DOI: 10.1016/j.apsusc.2012.07.101

[12] L.B. Li, Z.M. Chen, L.F. Xie, C. Yang, TEM Characterization of Si films grown on 6H–SiC (0001) C-face, Mater. Lett. 93 (2013) 330-332.

DOI: 10.1016/j.matlet.2012.11.093

[13] Z. Tsvetanka, K. Jagannadham, J. Narayan, Epitaxial growth in large-lattice-mismatch systems, J. Appl. Phys. 75 (1994) 860-871.

DOI: 10.1063/1.356440
