Potential of 4H-SiC CMOS for High Temperature Applications Using Advanced Lateral p-MOSFETs

Abstract:

In this work, the impact of the n-well doping concentration on the channel mobility and threshold voltage of p-MOSFETs and their applications in CMOS-devices is evaluated. For this purpose lateral p-channel MOSFETs with different channel lengths (L = 800 μm, 10 μm, 5 μm, and 3 μm) and doping concentrations (N_D = 10¹⁵ cm^-3 and 8·10¹⁵ cm^-3) were fabricated and the respective field-effect mobility was extracted from the transfer-characteristics. Comparable to n-MOSFETs the mobility of p-MOSFETs was found to be the highest for the lowest doping concentration in the channel and the absolute value of the threshold voltage increases with increasing doping concentration [4]. To investigate its suitability for CMOS applications, inverters with different doping concentrations for n-MOSFET (N_A = 10¹⁵ cm^-3 and 10¹⁷ cm^-3) und p-MOSFET (N_D = 10¹⁵ cm^-3 and 8·10¹⁵ cm^-3) were built. For logic levels of 0 V and 10 V, the voltage transfer characteristic with the highest input ranges was obtained for a low p-MOSFET and a high n-MOSFET doping concentration. The lowest propagation delay time could be achieved with a low p-MOSFET and a low n-MOSFET doping concentration. At room temperature as well as at high temperatures T = 573 K the drain current of p-MOSFETs with channel lengths below 3 μm is hampered by the series resistance of the source and drain region which limits the performance of CMOS devices.

• Periodical: Materials Science Forum (Volume 858)
• Pages: 821-824
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.858.821
• Online since: May 2016
• Authors: Matthaeus Albrecht*, Tobias Erlbacher, Anton J. Bauer, Lothar Frey
• Keywords: 4H-SiC, CMOS, Field-Effect Mobility, High Temperature, p-MOSFET

References

[1] D. Clark , E. P. Ramsay , A. E. Murphy , D. A. Smith , R. F. Thompson , R. A. R. Young , J. D. Cormack , J. McGonigal , C. Zhu , S. Finney, J. Fletcher, Mater. Sci. Forum, 679-680 (2011), 726.

DOI: 10.4028/www.scientific.net/msf.679-680.726

[2] S. Potbhare, N. Goldsman, G. Pennington, A. Lelis, J. M. McGarrity, J. Appl. Phys., (2006).

[3] C. Strenger, V. Uhnevionak, A. Burenkov, A. J. Bauer, P. Pichler, T. Erlbacher, H. Ryssel, L. Frey, ECS Trans., 58 (2013), 71.

DOI: 10.1149/05804.0071ecst

[4] C. Strenger, Herstellung und Charakterisierung von Metall-Oxid-Halbleiter-Kondensatoren und Feldeffekttransistoren auf 4H-Siliciumcarbid, Dissertation, Shaker, Aachen, (2015).

[5] D. Hodges, H. Jackson, R. Saleh, Analysis and Design of Digital Integrated Circuits, third ed., McGraw-Hill, New York, (2003).

[6] J. M. Pimbley, Advanced CMOS Process Technology, Academic Press, San Diego California, (1989).
