Joints Properties of Aluminum Foams/Aluminum Plate by Transient Liquid Phase Bonding Process

Abstract:

Aluminum foams/aluminum plate was transient liquid phase diffusion bonded with Cu/Al/Cu composite interlayer, then the investigation on joint microstructure, element diffusion and joint strength was conducted at 565°C. The results showed that, there was a significant grain boundary penetration phenomenon near the interface and it was more seriously at the side of aluminum foams. The XRD results showed indicated that the main phases near the interface were α-Al, CuAl₂, AlCu, Al₄Cu₉, Al₂O₃. By EDS line scanning, it indicated that the diffusion behavior of elements was different at three regions, compared with the edge region, the interface of the central region was better and the depth of element diffusion is larger, at the pore region, the liquefaction of interlayer was not successfully and the morphology was lamellar. Mechanical properties test showed that the largest shear strength of joint was 4.61 MPa when the duration was 40 min. Key words: Aluminum foams; transient liquid phase bonding; microstructure; element diffusion; shear strength

• Periodical: Materials Science Forum (Volume 944)
• Pages: 593-599
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.944.593
• Online since: January 2019
• Authors: Ben Sheng Huang*, Xiong Wen, Xing Zhao, Guang Wen Li
• Keywords: Aluminum Foams, Element Diffusion, Microstructure, Shear Strength, Transient Liquid Phase Bonding

References

[1] M. Zhang, G.Y. Zu, G.C. Yao, Bending properties of novel Aluminum foam sandwich panels, The Chinese Journal of Process Engineering, 7(3) (2007) 628-631.

[2] F.J. Yang, W.C. Lu, X.Y. He, Effect of core thickness and cell structure on flexural behavious of closed-cell aluminum foam sandwich beams, Journal of Southeast University (Natural Science Edition), 43(5) (2013) 1045-1049.

[3] N.N. Chen, Y. Feng, J. Chen, et al, Vacuum brazing processes of aluminum foam, Rare metal materials and engineering, 42(6) (2013) 1118-1122.

DOI: 10.1016/s1875-5372(13)60072-7

[4] G.W. Zhang, Y.F. Bao, Y.F. Jiang, et al, Microstructure and mechanical properties of 6063 aluminum alloy brazed joints with Al-Si-Cu-Ni-RE filler metal, Journal of Materials Engineering and Performance, 20(8) (2011) 1451-1456.

DOI: 10.1007/s11665-010-9802-2

[5] S.S. Wang, M.D. Cheng, L.C. Tsao, et al, Corrosion behaviors of Al-Si-Cu(Sn, Zn) brazing filler metals,Materials Characterization, 47(5) (2001) 401-409.

DOI: 10.1016/s1044-5803(02)00188-2

[6] H.Wang, D.P. He, X.M. Chu, et al, Interface structure of N2-shielded furnace brazing of Al foam and its mechanical properties, Transaction Of The China Welding Institution, 29 (10) (2008) 1-4.

[7] K J. Matthes, H. Lang, Brazing of aluminum foam with cellular fillermatals, Cellular Metals and Metals Foaming Technology. Bremen: Verlag MIT Publishing, (2001) 501-504.

[8] J H. Li, Research on brazing process and the property of Aluminum foam, Tianjin: Hebei University of Technology, (2015).

[9] N N. Chen, Research on vacuum brazing and contact reactive brazing of aluminum foam, Hefei: Hefei University of Technology, (2012).

[10] G.F. Zhang, J.X. Zhang, S.Y. Wang, et al, Similarities and differences in main characteristics between transient liquid phase bonding and brazing process, Transaction Of The China Welding Institution, 23(6) (2002) 92-93.

[11] W.F. Gale, D.A. Butts, Transient liquid phase bonding. science and technology of welding & joining, 9(4) (2004) 283-300.

DOI: 10.1179/136217104225021724

[12] Wang Xuegang. Microstructure and properties of Cu-Al dissimilar joint by transient liquid phase bonding, Jinan: Shandong University, (2015).

[13] W.H. Liu, TLP diffusion bonding of aluminum-based metal matrix composite, Changchun: Jilin University, (2004).

[14] Y.F. Song, Preparation, microstructure and mechanical properties of Al foam and Al foam sandwich panels, Changsha: Central South University, (2014).

[15] W.M. Zhang, X.M. Qiu, X.W. Chen, et al, Microstructure and mechanical property of transient liquid phase bonded Aluminum silicon alloy joint, Transaction Of The China Welding Institution, 30(2) (2009) 121-124.

[16] S.J. Guo, S.J. Chen, F. Liang, Effect of bonding pressure on transient liquid phase bonding process and joint properties of T91/12Cr2MoWVTiB, Hot Working Technology, 38(15) (2009) 95-97.

DOI: 10.4028/www.scientific.net/amr.97-101.107

[17] S.S.S. Afghahi, A. Ekrami, S. Farahany, et al, Effect of bonding parameters on microstructure development during TGTLP bonding of Al7075 alloy, Philosophical Magazine, 94(11) (2014) 1166-1176.

DOI: 10.1080/14786435.2014.885132

[18] R.K. Saha, T.I. Khan, Effect of bonding variables on TLP bonding of oxide dispersion strengthened superalloy, Journal of Materials Science, 42(22) (2007) 9187-9193.

DOI: 10.1007/s10853-007-1922-1
