Magnetic Anisotropy in [Pt/Co]₄/MgO/[Co/Pt]₂ Multilayers

Abstract:

A serial of [Pt/Co]₄/MgO/[Co/Pt]₂ multilayers were prepared by magnetron sputtering in this study and Antiferromagnetic (AF) interlayer coupling was observed with increasing MgO spacer thickness. Perpendicular magnetic anisotropy of soft layer in [Pt/Co]₄/MgO/[Co/Pt]₂ multilayers were measured by Extraordinary Hall Effect (EHE). The direction of the magnetic field was parallel to the direction of the current. The results revealed that perpendicular magnetic anisotropy constant K_u oscillates with the thickness of MgO layer which is between 1.3 to 3.3 nm. The period of this oscillation is about 0.43 nm. This is very close to the monolayer (100) MgO. With increasing MgO spacer, the periodic variation of interface between [Pt/Co]_n and MgO layer may be one of the reasons for this oscillation behavior of K_u.

• Periodical: Materials Science Forum (Volume 944)
• Pages: 625-630
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.944.625
• Online since: January 2019
• Authors: Qian Li, Lei Li*, Wei Zhou, Jun Chen, Si Yuan Zhang, Jian Hua Cai
• Keywords: Antiferromagnetic Interlayer Coupling, Extraordinary Hall Effect, Perpendicular Magnetic Anisotropy, Perpendicular Magnetic Tunnel Junctions

References

[1] S.S.P. Parkin, C. Kaiser, A. Panchula, P.M. Rice, B. Hughes, M. Samant, S.H. Yang, Giant tunnelling magnetoresistance at room temperature with MgO (100) tunnel barriers, Nature Mater. 3 (2004) 862-867.

DOI: 10.1038/nmat1256

[2] S. Yuasa, T. Nagahama, A. Fukushima, Y. Suzuki, K. Ando, Giant room-temperature magnetoresistance in single-crystal Fe/MgO/Fe magnetic tunnel junctions, Nature Mater. 3 (2004) 868-871.

DOI: 10.1038/nmat1257

[3] K. Tsunekawa, D. D. Djayaprawira, M. Nagai, H. Maehara, S. Yamagata, N. Watanabe, S. Yuasa, Y. Suzuki, K. Ando, Giant tunneling magnetoresistance effect in low-resistance CoFeB/MgO(001)/CoFeB magnetic tunnel junctions for read-head applications, Appl. Phys. Lett. 87 (2005) 072503.

DOI: 10.1063/1.2012525

[4] Y. Shiratsuchi, M. Yamamoto, S.D. Bader, Magnetism and Surface Structure of Atomically Controlled Ultrathin Metal Films, Prog. Surf. Sci. 82 (2007) 121-160.

DOI: 10.1016/j.progsurf.2006.08.001

[5] N. Nishimura, T. Hirai, A. Koganei, T. Ikeda, K. Okano, Y. Sekiguchi, Y. Osada, Magnetic tunnel junction device with perpendicular magnetization films for high-density magnetic random access memory, J. Appl. Phys. 91 (2002) 5246-5249.

DOI: 10.1063/1.1459605

[6] M. Bowen, V. Cros, F. Petroff, A. Fert, Large magnetoresistance in Fe/MgO/FeCo(001) epitaxial tunnel junctions on GaAs(001), Appl. Phys. Lett. 79 (2001) 1655-1657.

DOI: 10.1063/1.1404125

[7] H. Ohmori, T. Hatori, S. Nakagawa, Perpendicular magnetic tunnel junction with tunneling magnetoresistance ratio of 64% using MgO (100) barrier layer prepared at room temperature, J. Appl. Phys. 103 (2008) 07A911.

DOI: 10.1063/1.2840016

[8] B. Carvello, C. Ducruet, B. Rodmacq, S. Auffret, E. Gautier, G. Gaudin, B. Dieny, Sizable room-temperature magnetoresistance in cobalt based magnetic tunnel junctions with out-of-plane anisotropy, Appl. Phys. Lett. 92 (2008) 102508.

DOI: 10.1063/1.2894198

[9] I. Yoo, D.K. Kim, Y.K. Kim, Switching characteristics of submicrometer magnetic tunnel junction devices with perpendicular anisotropy, J. Appl. Phys. 97 (2005) 10C919.

DOI: 10.1063/1.1854282

[10] Y. Ochiai, S. Hashimoto, K. Aso, Co/Pt and Co/Pd ultrathin-multilayered films as new magneto-optical recording materials, IEEE Trans. Magn. 25 (2002) 3755-3757.

DOI: 10.1109/20.42423

[11] L. Néel, Magnetic surface anisotropy and superlattice formation by orientation, J. Phys. Radium 15 (1954) 225-239.

[12] F.A. Shah, V.K. Sankar, P. Li, G. Csaba, Compensation of orange-peel coupling effect in magnetic tunnel junction soft layer via shape engineering for nanomagnet logic applications, J. Appl. Phys. 115 (2014) 17B902.

DOI: 10.1063/1.4863935

[13] L. Li, F. Zhang, N. Wang, Y. F. Lv, X. Y. Han, J. J. Zhang, Interlayer exchange coupling and its temperature dependence in [Pt/Co]4/MgO/[Co/Pt]2 perpendicular magnetic tunnel junctions, J. Appl. Phys. 108 (2010) 073908.

DOI: 10.1063/1.3490134

[14] P. Bruno, Theory of intrinsic and thermally induced interlayer magnetic coupling between ferromagnetic films separated by an insulating layer, Phys. Rev. B 49 (1994) 13231-13234.

DOI: 10.1103/physrevb.49.13231

[15] C.M. Lee, J.M. Lee, L.X. Ye, S.Y. Wang, Y.R. Wang, T.H. Wu, Effects of MgO Barrier Thickness on Magnetic Anisotropy Energy Constant in Perpendicular Magnetic Tunnel Junctions of (Co/Pd) /MgO/(Co/Pt), IEEE trans. Magn. 44 (2008) 2558-2561.

DOI: 10.1109/tmag.2008.2002594

[16] E.C. Stoner, E.P. Wohlfarth, A mechanism of magnetic hysteresis in heterogeneous alloys, IEEE Transactions on Magnetics, 27 (2003) 3475-3518.

DOI: 10.1109/tmag.1991.1183750

[17] Te-Ho. Wu, H. Fu, R. A. Hajjar, M. Mansuripur, Measurement of magnetic anisotropy constant for magneto-optical recording media: A comparison of several techniques, J. Appl. Phys. 73 (1993) 1368-1376.

DOI: 10.1063/1.353256
