Effect of Ca and Zr Additions and Aging Treatments on Microstructure and Mechanical Properties of Mg-Sn Alloy

Abstract:

The effect of Ca and Zr Additions and Aging Treatments on Microstructure and Mechanical Properties of Mg-Sn alloy was investigated. It was found that the grain size of as-cast Mg-4Sn-xCa and Mg-4Sn-xZr alloys was refined with the increase of alloying elements addition. The alloys were solution-treated at 480 °C and aged at 160 °C, and the aging peak appeared after 4-5 h. The difference was that the maximum tensile strength and Brinell hardness of Mg-4Sn-0.3Ca were 140.7 MPa and 44.5 HB, respectively, while in Mg-4Sn-xZr alloy, Mg-4Sn-0.5Zr was optimal. The maximum tensile strength and Brinell hardness of Mg-4Sn-0.5Zr were 137.4 MPa and 41.5 HB, respectively. This difference was mainly due to the formation of the brittle phase CaMgSn in the Mg-4Sn-xCa alloy. The excessive brittle phase was not conducive to the strength of the alloy, but could increase the hardness of the alloy. However, Zr existed as a simple substance in the alloy, which can be used as a nucleation particle to inhibit grain growth and play a role of fine grain strengthening. But the addition of Zr did not form many hard phases, so the hardness did not change much.

• Periodical: Materials Science Forum (Volume 993)
• Pages: 152-160
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.993.152
• Online since: May 2020
• Authors: Fan Wang, Yun Feng, Ming Shi Li, Xin Ying Teng*
• Keywords: Aging Treatment, Magnesium Alloys, Microstructure, Solution Treatment

References

[1] Mordike B L, Ebert T. Magnesium: properties—applications—potential[J]. Materials Science and Engineering: A, 2001, 302(1): 37-45.

[2] Liu H, Chen Y, Tang Y, et al. The microstructure, tensile properties, and creep behavior of as-cast Mg-(1–10) % Sn alloys[J]. Journal of Alloys and Compounds, 2007, 440(1-2): 122-126.

DOI: 10.1016/j.jallcom.2006.09.024

[3] Qu H P, Wang H M. Microstructure and mechanical properties of laser melting deposited γ-TiAl intermetallic alloys[J]. Materials Science and Engineering: A, 2007, 466(1-2): 187-194.

DOI: 10.1016/j.msea.2007.02.073

[4] Huang X, Wu A, Li Q, et al. Effects of extrusion and Ag, Zn addition on the age-hardening response and microstructure of a Mg-7Sn alloy[J]. Materials Science and Engineering: A, 2016, 661: 233-239.

DOI: 10.1016/j.msea.2016.03.037

[5] Zhao C Y, Pan F S, Pan H C. Microstructure, mechanical and bio-corrosion properties of as-extruded Mg–Sn–Ca alloys[J]. Transactions of Nonferrous Metals Society of China, 2016, 26(6):1574-1582.

DOI: 10.1016/s1003-6326(16)64232-2

[6] Sasaki T T, Ju J D, Hono K, et al. Heat-treatable Mg–Sn–Zn wrought alloy[J]. ScriptaMaterialia, 2009, 61(1): 80-83.

DOI: 10.1016/j.scriptamat.2009.03.014

[7] Zhao H D, Qin G W, Ren Y P, et al. Microstructure and tensile properties of as-extruded Mg-Sn-Y alloys[J]. Transactions of Nonferrous Metals Society of China, 2010, 20: s493-s497.

DOI: 10.1016/s1003-6326(10)60525-0

[8] Myshlyaev M M, McQueen H J, Mwembela A, et al. Twinning, dynamic recovery and recrystallization in hot worked Mg–Al–Zn alloy[J]. Materials Science and Engineering: A, 2002, 337(1-2): 121-133.

DOI: 10.1016/s0921-5093(02)00007-2

[9] Kang D H, Park S S, Kim N J. Development of creep resistant die cast Mg–Sn–Al–Si alloy[J]. Materials Science and Engineering: A, 2005, 413: 555-560.

DOI: 10.1016/j.msea.2005.09.022

[10] Pan F, Yang M. Preliminary investigations about effects of Zr, Sc and Ce additions on as-cast microstructure and mechanical properties of Mg–3Sn–1Mn (wt.%) magnesium alloy[J]. Materials Science and Engineering: A, 2011, 528(15): 4973-4981.

DOI: 10.1016/j.msea.2011.02.095

[11] Li W, Huang X, Huang W. Effects of Ca, Ag addition on the microstructure and age-hardening behavior of a Mg-7Sn (wt%) alloy[J]. Materials Science and Engineering: A, 2017, 692: 75-80.

DOI: 10.1016/j.msea.2017.03.066

[12] Mehta D S, Masood S H, Song W Q. Investigation of wear properties of magnesium and aluminum alloys for automotive applications[J]. Journal of Materials Processing Technology, 2004, 155-156(6):1526-1531.

DOI: 10.1016/j.jmatprotec.2004.04.247

[13] Zhiyong Y, Yuhua Z, Weili C, et al. Effect of Cu addition on microstructure and properties of Mg-10Zn-5Al-0.1 Sb high zinc magnesium alloy[J]. China Foundry, 2012, 9(1).

[14] Li J, Qu Z, Wu R, et al. Effects of Cu addition on the microstructure and hardness of Mg–5Li–3Al–2Zn alloy[J]. Materials Science and Engineering: A, 2010, 527(10-11): 2780-2783.

DOI: 10.1016/j.msea.2010.01.021

[15] Nayyeri G, Mahmudi R. Effects of Ca additions on the microstructural stability and mechanical properties of Mg–5% Sn alloy[J]. Materials & Design, 2011, 32(3): 1571-1576.

DOI: 10.1016/j.matdes.2010.09.019

[16] Shi B Q, Chen R S, Wei K E. Effect of element Gd on phase constituent and mechanical property of Mg-5Sn-1Ca alloy[J]. Transactions of Nonferrous Metals Society of China, 2010, 20: s341-s345.

DOI: 10.1016/s1003-6326(10)60494-3

[17] Lee B J, Hwang N M, Lee H M. Prediction of interface reaction products between Cu and various solder alloys by thermodynamic calculation[J]. Acta Materialia, 1997, 45(5): 1867-1874.

DOI: 10.1016/s1359-6454(96)00325-4
