Static Analysis of Temperature-Dependence of Paralleled High Voltage Vertical Silicon & SiC NPN BJTs

Abstract:

This paper compares the static properties for Silicon & SiC BJTs when connected in parallel, under various operating temperatures at various base currents and collector currents. This includes analysis of forward I-V characteristics, on-state resistance, DC gain, forward transfer characteristics and reverse leakage current to provide insights on paralleling of SiC & SiC BJTs.
