HomeKey Engineering MaterialsKey Engineering Materials Vol. 1021Superior Characteristics of Body Diode in DMOSFET...

Superior Characteristics of Body Diode in DMOSFET Fabricated on 4H-SiC Bonded Substrate

Abstract:

A novel substrate of 4H-SiC bonded substrate is expected to solve issues such as decreasing the on-resistance, which has attracted much attention. Therefore, several studies have been conducted on the use of bonded substrates. In this study, we fabricated a DMOSFET on a bonded substrate and compared its static and dynamic characteristics with those on a single-crystal substrate. Consequently, the on-resistance of the DMOSFET fabricated on a bonded substrate was lower than that on a single-crystal substrate owing to the low resistivity of the polycrystalline substrate. Also, reverse recovery loss of the DMOSFET fabricated on a bonded substrate was lower than that on single-crystal substrate at high temperature due to low carrier lifetime in a drift layer. Additionally, we observed that the DMOSFET fabricated on a bonded substrate did not generate bipolar degradation despite the application of a forward-current stress of over 1500 A cm^-². According to these results, we expected that the carrier lifetime in both drift layer and transfer layer was decreased on a bonded substrate.

By email View Pdf

You have full access to the following eBook

Read eBook

Info:

Periodical:

Key Engineering Materials (Volume 1021)

Pages:

59-67

DOI:

https://doi.org/10.4028/p-5KX9qK

Citation:

Cite this paper

Online since:

September 2025

Authors:

Yuta Higashi*, Seiji Ishikawa, Kunihide Oozono, Hiroshi Sezaki, Motoki Kobayashi, Hidetsugu Uchida, Mitsuo Okamoto, Shinsuke Harada, Kazutoshi Kojima, Tomohisa Kato, Yasunori Tanaka

Keywords:

Bipolar Degradation, Bonded Substrate, DMOSFET, Dynamic Characteristics, High Temperature Reliability, Static

Export:

RIS, BibTeX

Permissions:

Creative Commons CC BY 4.0

Citation:

* - Corresponding Author

References

[1] S. Rouchier, G. Gaudin, J. Widiez, Materials Science Forum 1062, p.131, (2022)

Google Scholar

[2] H. Biard, S. Odoul, W. Schwarzenbach, I. Radu, C. Maleville, A. Potier, M. Ferrato, E. Guajioty Solid State Phenomena 344, p.47, (2023)

DOI: 10.4028/p-65127n

Google Scholar

[3] M. Kobayashi, H. Uchida, N. Hatta, S. Ishikawa, Y. Higashi, H. Sezaki, S. Harada, K. Kojima, Abstract of ICSCRM, (2024)

Google Scholar

[4] N. Hatta, M. S. Ishikawa, K. Ozono, K. Masumoto, K. Yagi, M. Kobayashi, S. Kurihara, S. Harada, K. Kojima, Key Engineering Materials 948, p.107, (2023)

DOI: 10.4028/p-628fu5

Google Scholar

[5] H. Uchida, M. Kobayashi, N. Hatta, S. Ishikawa, K. Ozono, K. Masumoto, S. Kurihara, S. Harada, K. Kojima, Proceeding of ICSCRM, p.209, (2023)

Google Scholar

[6] H. Uchida, M. Kobayashi, N. Hatta, S. Ishikawa, Y. Higashi, K. Masumoto, S. Kurihara, S. Harada, K. Kojima, Abstract of ICSCRM, (2024)

Google Scholar

[7] G. Wang, L. Yuan, X. Wang, Y. Zhang. R. Jia, Journal of Crystal Growth 606, 127086, (2023)

Google Scholar

[8] Information on https://www.sicoxs.com/en/product/

Google Scholar
