Comparison of the Performance-Degrading Near-Interface Traps in Commercial SiC MOSFETs

Abstract:

This paper presents a comparison of the density of performance-degrading near-interface traps (NITs) in the most commonly available 1200 V commercial N-channel SiC power metal–oxide–semiconductor field-effect transistors (MOSFETs). A recently developed integrated-charge technique was used to measure the density of NITs with energy levels aligned to the conduction band, which degrade MOSFET’s performance by capturing and releasing electrons from the channel biased in the strong-inversion condition. Trench MOSFETs of one manufacturer have lower densities of these NITs in comparison to MOSFETs with the planar gate structure, corresponding to observed higher channel-carrier mobility in trench MOSFETs. Different response-time distributions were also observed, corresponding to different spatial location of the measured NITs.

• Periodical: Materials Science Forum (Volume 1091)
• Pages: 25-29
• DOI: https://doi.org/10.4028/p-258768
• Online since: June 2023
• Authors: Mayank Chaturvedi*, Sima Dimitrijev, Daniel Haasmann, Hamid Amini Moghadam, Peyush Pande, Utkarsh Jadli
• Keywords: Characterization Technique, Commercial 4H-SiC MOSFET, Device Performance, Near-Interface Traps

References

[1] H. Yoshioka, T. Nakamura, and T. Kimoto, Accurate evaluation of interface state density in SiC metal-oxide-semiconductor structures using surface potential based on depletion capacitance, J. Appl. Phys. 111(1) (2012) 014502.

DOI: 10.1063/1.3673572

[2] T. Kimoto, and H. Watanabe, Defect engineering in SiC technology for high-voltage power devices, Appl. Phys. Express 13 (2020) 120101.

DOI: 10.35848/1882-0786/abc787

[3] P. Fiorenza, F. Giannazzo, and F. Roccaforte, Characterization of SiO2/4H-SiC Interfaces in 4H SiC MOSFETs: A Review, Energies 12 (2019) 2310.

DOI: 10.3390/en12122310

[4] A.J. Lelis, R. Green, and D.B. Habersat, SiC MOSFET threshold-stability issues, Mater. Sci. Semicond. Process 78 (2018) 32-37.

DOI: 10.1016/j.mssp.2017.11.028

[5] D. Haasmann, and S. Dimitrijev, Energy position of the active near-interface traps in metal-oxide-semiconductor field-effect transistors on 4H-SiC, Appl. Phys. Lett. 103 (2013) 113506.

DOI: 10.1063/1.4821362

[6] R. Y. Khosa, and E. Ö. Sveinbjörnsson, Conductance signal from near-interface traps in n-type 4H-SiC MOS capacitors under strong accumulation, Mater. Sci. Forum 897 (2017) 147-150.

DOI: 10.4028/www.scientific.net/msf.897.147

[7] M. Chaturvedi, S. Dimitrijev, D. Haasmann, H.A. Moghadam, P. Pande, and U. Jadli, Quantified density of performance-degrading near-interface traps in SiC MOSFETs, Sci. Rep. 12 (2022) 4076.

DOI: 10.1038/s41598-022-08014-5

[8] F. Triendl, G. Fleckl, M. Schneider, G. Pfusterschmied, and U. Schmid, Evaluation of interface trap characterization methods in 4H-SiC metal oxide semiconductor structures over a wide temperature range, J. Vac. Sci. Tech. B 37 (2019) 032903.

DOI: 10.1116/1.5094137

[9] P. Pande, D. Haasmann, J. Han, H.A. Moghadam, P. Tanner, and S. Dimitrijev, Electrical characterization of SiC MOS capacitors: A critical review, Microelectron. Reliab. 112 (2020) 113790.

DOI: 10.1016/j.microrel.2020.113790

[10] M. Chaturvedi, S. Dimitrijev, D. Haasmann, H.A. Moghadam, P. Pande, and U. Jadli, A figure of merit for selection of the best family of SiC power MOSFETs, Electronics 11 (2022) 1433.

DOI: 10.3390/electronics11091433

[11] B. J. Baliga, Fundamentals of power semiconductor devices, Springer-Verlag, New York, NY, USA, 2010.

[12] M. Chaturvedi, S. Dimitrijev, D. Haasmann, H.A. Moghadam, P. Pande, and U. Jadli, Comparison of commercial planar and trench SiC MOSFETs by electrical characterization of performance-degrading near-interface traps, IEEE Trans. Electron Devices 69 (2022) 6225-6230.

DOI: 10.1109/ted.2022.3206184
