Electrical Characterization of Metastable Defects Introduced in GaN by Eu-Ion Implantation

Abstract:

Gallium nitride (GaN), grown by HVPE, was implanted with 300 keV Eu ions and then annealed at 1000 oC . Deep level transient spectroscopy (DLTS) and Laplace DLTS (L-DLTS) were used to characterise the ion implantation induced defects in GaN. Two of the implantation induced defects, E1 and E2, with DLTS peaks in the 100 – 200 K temperature range, had DLTS signals that could be studied with L-DLTS. We show that these two defects, with energy levels of 0.18 eV and 0.27 eV below the conduction band, respectively, are two configurations of a metastable defect. These two defect states can be reproducibly removed and re-introduced by changing the pulse, bias and temperature conditions, and the transformation processes follow first order kinetics.
