Recombination and Excess Currents in 4H-SiC Structure with Low-Doped n-Region

Abstract:

Presented in this paper are the results of a study of forward and reverse current-voltage characteristics of the 4H-SiC pn structures produced by implantation of Al+ ions in low-doped ((5-7)∙1014cm-3) n-type conductivity epitaxial layer. A forward current was identified which is consistent with the model of recombination in the space charge region of a pn junction via a deep level: J=Joexp(qU/nkT), where Jo=Jo*exp[-Ea/(kT)] (or J= Jo*exp[(qU-2Ea)/nkT)]) with the ideality factor n=2. Parameters of this current are as follows: Jo(293 K) ~ 8∙10-25 A/cm2, Ea 1.73-1.75 eV (2Ea3.46-3.5 eV), Jo*~7∙105 A/cm2. A comparison of the experimental and model-based values of Ea, with allowance for all clearly defined temperature dependences, both strong and weak, of the model of recombination in the space charge region shows that the effective lifetime increases and effective trapping cross section σeff of the recombination level decreases with increasing temperature: σeff ~ T-2÷σeff ~ T-2.5 or σeff ~exp(ΔE /kT) where ΔE=80-100 meV. Reverse current practically in whole temperature range is excess current, only at high temperatures (~800 K) reverse current became close to generation current in space charge region. Special interest are the excess currents as a result of the application of a reverse or forward voltage at high temperature. The barrier type excess currents is characteristic of SiC.

You might also be interested in these eBooks

Silicon Carbide and Related Materials 2012

View Preview

Info:

Periodical:

Materials Science Forum (Volumes 740-742)

Pages:

565-568

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.740-742.565

Citation:

Cite this paper

Online since:

January 2013

Authors:

Anatoly M. Strel'chuk, Evgenia V. Kalinina

Keywords:

4H-SiC, Excess Current, Lifetime, pn Structures, Recombination Current

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] C.-T. Sah, R. N. Noyce, W. Shockley, Carrier generation and recombination in p-n junction characteristics, Proc.of the I.R.E. 45 (1957) 1228-1243.

DOI: 10.1109/jrproc.1957.278528

Google Scholar

[2] A. M. Strel`chuk, N. S. Savkina, Ideal 4H-SiC pn junction and its characteristic shunt, Mater. Sci. Eng. B80 (2001) 378-382 and A. M. Strel'chuk, A .V. Mashichev, A. A. Lebedev, A. A. Volkova, K. Zekentes, About nature of recombination current in 4H-SiC pn structure, Mat. Sci. Forum 527-529 (2006) 1343-1346.

DOI: 10.4028/www.scientific.net/msf.527-529.1343

Google Scholar

[3] M. E. Levinshtein, S. L. Rumyantsev, M. S. Shur, Properties of advanced semiconductor materials: GaN, AlN, InN, BN, SiC, SiGe, John Wiley and sons, Inc., 2001.

Google Scholar

[4] A. M. Strel'chuk, Lifetimes and diffusion lengths of nonequilibrium charge carriers in SiC p-n structures, Semiconductors 29 (1995) 614-623.

Google Scholar

[5] T. Hayashi, K. Asano, J. Suda, T. Kimoto, Temperature and injection level dependencies of carrier lifetime in p-type and n-type 4H-SiC epilayers, Mater. Sci. Forum 645-648 (2010) 199-202, and P. B. Klein, R. Myers-Ward, K.-K. Lew, B. L. VanMil, C. R. Eddy, Jr., D. K. Gaskill, A. Shrivastava, T. S. Sudarshan, Temperature dependencies of the carrier lifetime in 4H-SiC epilayers, Mater. Sci. Forum 645-648 (2010) 203-206.

DOI: 10.4028/www.scientific.net/msf.645-648.203

Google Scholar

[6] A. M. Strel'chuk, E. V. Kalinina, G. A. Onushkin, A .O. Konstantinov, A. Hallén, Features of current-voltage characteristics of Cr Schottky diodes based on low-doped 4H-SiC, V International seminar on Silicon Carbide and Related Materials (ISSCRM-2004), Abstracts, Velikiy Novgorod, Russia (2004) 116-117, and A. M. Strel'chuk, M. G. Rastegaeva, Characterization Schottky barriers occurring at the metal-6H-SiC contact based on results of studies of current-voltage characteristics, Mat. Sci. & Ing. B46 (1997) 379-382.

DOI: 10.1016/s0921-5107(96)02010-7

Google Scholar

[7] A. M. Strel'chuk, V. V. Evstropov, M. G. Rastegaeva, E. P. Kuznetsova, Shunting patterns occurring in epitaxial 6H-SiC p-n structures for high-voltage rectifiers, Mat. Sci. & Ing. B46 (1997) 231-235.

DOI: 10.1016/s0921-5107(96)01979-4

Google Scholar

[8] H. Lendenmann, F. Dahlquist, J. P. Bergman, H. Bleichner, C. Hallin, High-power diodes: characteristics, reliability and relation to material defects, Mat. Sci. Forum 389-393 (2002) 1259-1264 and Q. Zhang, A. Agarwal, A. Burk, M. O'Loughlin, J. Palmour, R. Stahlbush, C. Scozzie, Influence of Shockley stacking fault generation on electrical behavior of 4H-SiC 10 kV MPS diodes, Mat. Sci. Forum 645-648 (2010) 331-334.

DOI: 10.4028/www.scientific.net/msf.645-648.331

Google Scholar
