Drain-Current Deep Level Transient Spectroscopy Investigation on Epitaxial Graphene/6H-SiC Field Effect Transistors

Abstract:

The electrically active deep levels in a graphene / silicon carbide field effect transistor (FET) were investigated by drain-current deep level transient spectroscopy (I_D-DLTS). An evaluation procedure for I_D-DLTS is developed in order to obtain the activation energy, the capture cross section and the trap concentration. We observed three defect centers corresponding to the intrinsic defects E₁/E₂, E_i and Z₁/Z₂ in n-type 6H-SiC. The determined parameters have been verified by conventional capacitance DLTS.
