Effect of Phosphorus Implantation Prior to Oxidation on Electrical Properties of Thermally Grown SiO2/4H-SiC MOS Structures

Article Preview

Abstract:

The electrical properties of metal-oxide-semiconductor (MOS) devices fabricated using dry oxidation on phosphorus-implanted n-type 4H-SiC (0001) epilayers have been investigated. MOS structures were compared in terms of interface traps and reliability with reference sample which was produced by dry oxidation under the same conditions. The notably lower interface traps density measured in MOS capacitor with phosphorus concentration exceeding 1018 cm-3 at the SiO2/SiC interface was attributed to interface traps passivation by incorporated phosphorus ions.
