Early-Stage Reliability Evaluation of Passivation Stack and Termination Designs in SiC MPS Diodes

Abstract:

We present an early-stage reliability evaluation approach to assess the impact of surface charges in the passivation overcoat (PO) film layers. This is obtained by applying a so-called accelerated wafer-level reverse breakdown voltage stability test in combination with wafer-level static and Van der Pauw measurements. Here, we applied this approach on 4H-SiC merged PiN Schottky diodes with a single-zone junction termination extension fabricated by using different border doses and PO stacks. Accordingly, the correlation between design parameters and the influence of surface charges can be quickly identified, leading to reduced cycle time and enhanced product reliability by optimizing the design of the JTE parameters already in the development phase. This study supports diodes and MOSFETs product manufacturing with an efficient optimization approach to address design and process impacts toward acquiring long-term lifetime demanded in automotive and industrial applications.

By email View Pdf

You might also be interested in these eBooks

20th International Conference on Silicon Carbide and Related Materials (ICSCRM 2023)

View Preview

Solid-State Power Devices: Operational Reliability and Parameters' Stability

View Preview

Info:

Periodical:

Solid State Phenomena (Volume 361)

Pages:

33-38

DOI:

https://doi.org/10.4028/p-S31g4f

Citation:

Cite this paper

Online since:

August 2024

Authors:

Davood Momeni*, Massimo Mazzillo, Sibasish Laha, M. Sazrin B. Abd. Sani, Jesus Urresti, Tian Xiang Dai, Christian Liguda, Soenke Habenicht

Keywords:

Accelerated Wafer-Level BVR Reliability Test, Ionic-Mobile Charges, Protection Overcoat Design, Silicon Carbide MPS Diode, Single-Zone Junction Termination Extension

Export:

RIS, BibTeX

Permissions:

Creative Commons CC BY 4.0

Citation:

* - Corresponding Author
