Dynamic Bias-Temperature Instability Testing in SiC MOSFETs

Abstract:

For power converter development in mission critical applications, the attractive performances of SiC power MOSFETs are shadowed by reliability concerns, particularly those induced by the defects at the gate dielectric. Charge trapping at the oxide-semiconductor interface can lead to threshold voltage drift, degrading the power converter efficiency and lifetime. The scope of this contribution is to show a testing methodology under development to understand SiC power MOSFET threshold voltage stability under dynamic and accelerated operating conditions. The presented testing methodology relies on switching the device under test at high-voltage and current, simultaneously applying a gate stress and extracting threshold voltage from switching transients. The paper outlines the setup description, its operating modes and intended design of experiment to assess SiC MOSFET threshold voltage stability.

• Periodical: Solid State Phenomena (Volume 361)
• Pages: 59-64
• DOI: https://doi.org/10.4028/p-51NBYj
• Online since: August 2024
• Authors: Edoardo Martino*, Slavo Kicin, Yuan Zong, Ahmad Nasralla, Gianpaolo Romano, Ralph Burkart, Athanasios Mesemanolis, Stephan Wirths
• Keywords: Bias-Temperature Instability, Double Pulse Test, Gate Switching Instability (GSI), SiC Reliability

References

[1] Baliga, B. Jayant. Fundamentals of power semiconductor devices. Springer Science & Business Media, 2010.

[2] Green, Ronald, Aivars Lelis, and Daniel Habersat. "Application of reliability test standards to SiC Power MOSFETs." 2011 International Reliability Physics Symposium. IEEE, 2011.

DOI: 10.1109/irps.2011.5784573

[3] Lutz, Josef, and Jörg Franke. "Reliability and reliability investigation of wide-bandgap power devices." Microelectronics Reliability 88 (2018): 550-556.

DOI: 10.1016/j.microrel.2018.07.001

[4] Pantelides, Sokrates T., et al. "Si/SiO2 and SiC/SiO2 interfaces for MOSFETs–challenges and advances." Materials science forum. Vol. 527. Trans Tech Publications Ltd, 2006: 935–948.

[5] Wang, Sanwu, et al. "Bonding at the SiC− SiO 2 Interface and the effects of nitrogen and hydrogen." Physical review letters 98.2 (2007): 026101.

[6] Lelis, Aivars J., et al. "Basic mechanisms of threshold-voltage instability and implications for reliability testing of SiC MOSFETs." IEEE Transactions on Electron Devices 62.2 (2014): 316-323.

DOI: 10.1109/ted.2014.2356172

[7] Grasser, Tibor, Ben Kaczer, Wolfgang Goes, Th Aichinger, Ph Hehenberger, and M. Nelhiebel. "A two-stage model for negative bias temperature instability." In 2009 IEEE international reliability physics symposium, pp.33-44. IEEE, 2009.

DOI: 10.1109/irps.2009.5173221

[8] Grasser, Tibor, K. Rott, H. Reisinger, Michael Waltl, J. Franco, and Ben Kaczer. "A unified perspective of RTN and BTI." In 2014 IEEE International Reliability Physics Symposium, pp. 4A-5. IEEE, 2014.

DOI: 10.1109/irps.2014.6860643

[9] Grasser, Tibor, Ben Kaczer, Wolfgang Goes, Hans Reisinger, Thomas Aichinger, Philipp Hehenberger, Paul-Jürgen Wagner et al. "The paradigm shift in understanding the bias temperature instability: From reaction–diffusion to switching oxide traps." IEEE Transactions on Electron Devices 58, no. 11 (2011): 3652-3666.

DOI: 10.1109/ted.2011.2164543

[10] Salmen, Paul, Maximilian W. Feil, Katja Waschneck, Hans Reisinger, Gerald Rescher, and Thomas Aichinger. "A new test procedure to realistically estimate end-of-life electrical parameter stability of SiC MOSFETs in switching operation." In 2021 IEEE International Reliability Physics Symposium (IRPS), pp.1-7. IEEE, 2021.

DOI: 10.1109/irps46558.2021.9405207

[11] Salmen, P., M. W. Feil, K. Waschneck, H. Reisinger, G. Rescher, I. Voss, M. Sievers, and T. Aichinger. "Gate-switching-stress test: Electrical parameter stability of SiC MOSFETs in switching operation." Microelectronics reliability 135 (2022): 114575.

DOI: 10.1016/j.microrel.2022.114575

[12] Feil, Maximilian W., Katja Waschneck, Hans Reisinger, Judith Berens, Thomas Aichinger, Paul Salmen, Gerald Rescher, Wolfgang Gustin, and Tibor Grasser. "Towards Understanding the Physics of Gate Switching Instability in Silicon Carbide MOSFETs." In 2023 IEEE International Reliability Physics Symposium (IRPS), pp.1-10. IEEE, 2023.

DOI: 10.1109/irps48203.2023.10117740
