Investigation of Advanced Hexagonal Layouts for 650 V SiC MOSFETs

Abstract:

A set of novel features for the planar gate SiC MOSFETs with the hexagonal unit cell were investigated in terms of the R_DS,ON and reliability (HTRB/HTGB) perspectives. The fabricated SiC MOSFETs with the proposed features improved the R_DS,ON by 9~14% compared to the SiC MOSFETs with the conventional striped unit cell. From the R _DS,ON temperature coefficient perspective (RT Vs. 150°C), the SiC MOSFETs with the proposed features were close to the same counterpart with the marginal difference of ~2%. The SiC MOSFETs with the proposed features showed tighter R_DS,ON and I _D,SS spatial distributions in comparison to the SiC MOSFETs without the proposed features. Two batches of the SiC MOSFETs with select feature were tested for HTRB under the over-stressed conditions. One batch passed the 1,000hr HTRB test and another batch had one I _D,SS failure at 600hr with no further failure up until 1,000hr.

By email View Pdf

You have full access to the following eBook

Read eBook

Info:

Periodical:

Key Engineering Materials (Volume 1023)

Pages:

39-46

DOI:

https://doi.org/10.4028/p-e2ZeVx

Citation:

Cite this paper

Online since:

September 2025

Authors:

Jae Hoon Park*, Siddarth Sundaresan, Aditi Agarwal, Vamsi Mulpuri, Steven Dail, Yu Dong, Nathaniel Walsh

Keywords:

HEXFET, Planar Gate SiC MOSFET

Export:

RIS, BibTeX

Permissions:

Creative Commons CC BY 4.0

Citation:

* - Corresponding Author

References

[1] International Rectifier, HEXFET Databook 1982-1983

Google Scholar

[2] K. Han and B. Baliga, "The 1.2-kV 4H-SiC OCTFET: A new cell topology with improved high-frequency figures-of-merit," IEEE Electron Device Letters, vol. 40, no. 2, p.299–302, 2018.

DOI: 10.1109/led.2018.2889221

Google Scholar

[3] K. Han, et al., "Comparison of Four Cell Topologies for 1.2-kV Accumulation- and Inversion-Channel 4H-SiC MOSFETs: Analysis and Experimental Results," IEEE Transactions on Electron Devices, vol. 66, issue 5, p.2321 – 2326, 2019.

DOI: 10.1109/ted.2019.2905736

Google Scholar

[4] A. Agarwal, et al., "Impact of Cell Topology on Characteristics of 600V 4H-SiC Planar MOSFETs," IEEE EDL, vol. 40, issue 5, pp.773-776, 2019.

DOI: 10.1109/led.2019.2908078

Google Scholar

[5] S. Zhu et al, "A New Cell Topology for 4H-SiC Planar Power MOSFETs and Comparison with Hexagonal and Octagonal Cell Topologies," IEEE WiPDA, 2022.

DOI: 10.1109/wipda56483.2022.9955263

Google Scholar
