Evaluation of Suppressing Forward Voltage Degradation by Using a Low BPD Density Substrate or an Epitaxial Wafer with an HNDE

Abstract:

Forward voltage degradation is a crucial problem that must be overcome if we are to fabricate a metal-oxide semiconductor field-effect transistor (MOSFET) including a pin diode (PND) as a body diode in a silicon carbide (SiC). Previously, the basal plane dislocation (BPD) in a SiC substrate have been reduced to suppress bipolar degradation. On the other hand, an highly N-doped epilayer (HNDE) was recently fabricated that enhances the minority carrier recombination before the carrier arrives at the substrate. Although both approaches can reduce the V_f shift caused by the degradation, they should be used under different substrate conditions. When a substrate with a high BPD density is used for epitaxial growth, an HNDE is needed to realize a high-quality epitaxial wafer; however, the HNDE should not be formed on a substrate with a low BPD density.
