A Study of 4H-SiC Semi-Superjunction Rectifiers for Practical Realisation

Abstract:

This paper discusses the design and simulation of 4H-SiC semi-SJ structures producing results that are below the unipolar limit, whilst also ensuring practical and cost-effective realisation. The results demonstrate that a semi-SJ structure with a 10° sidewall angle increases the implantation window of the device by 45%, relative to the full-SJ, whilst maintaining a high V_BD of ~2 kV and a low R_ON,SP. This design facilitates a wide implantation window with a reduced trench aspect ratio, significantly improving the practical realisation of the device. It also offers softer reverse recovery characteristics as a result of both the angled trench sidewall and the n-bottom assist layer (n‑BAL) which allows for the structure to be depleted gradually.

• Periodical: Materials Science Forum (Volume 1062)
• Pages: 514-518
• DOI: https://doi.org/10.4028/p-cxd7z3
• Online since: May 2022
• Authors: G.W.C. Baker*, Fan Li, Tian Xiang Dai, A. Benjamin Renz, Lu Yang Zhang, Yun Yi Qi, Vishal Ajit Shah, Philip Andrew Mawby, Marina Antoniou, Peter Michael Gammon
• Keywords: Schottky Barrier Diode, Semi-Superjunction, Simulation, Superjunction

References

[1] B. J. Baliga, Fundamentals of power semiconductor devices. Springer Science & Business Media, (2010).

[2] Y. Yonezawa, Recent Progress in High to Ultra-High-Voltage SiC Power Devices: Development and Application,, in 2018 International Power Electronics Conference (IPEC-Niigata 2018-ECCE Asia), 2018: IEEE, pp.3603-3606.

DOI: 10.23919/ipec.2018.8507668

[3] R. Kosugi et al., Breaking the Theoretical Limit of 6.5 kV-Class 4H-SiC Super-Junction (SJ) MOSFETs by Trench Filling Epitaxial Growth,, in ISPSD, Shanghai, China, May 19-23 (2019).

DOI: 10.1109/ispsd.2019.8757632

[4] M. Baba et al., Ultra-Low Specific on-Resistance Achieved in 3.3 kV-Class SiC Superjunction MOSFET,, in 2021 33rd International Symposium on Power Semiconductor Devices and ICs (ISPSD), 2021: IEEE, pp.83-86.

DOI: 10.23919/ispsd50666.2021.9452273

[5] G. Baker et al., Optimization of 1700-V 4H-SiC Superjunction Schottky Rectifiers With Implanted P-Pillars for Practical Realization,, IEEE Transactions on Electron Devices, vol. 68, no. 7, pp.3497-3504, (2021).

DOI: 10.1109/ted.2021.3083241

[6] H.-K. Sung et al., Vertical and bevel-structured SiC etching techniques incorporating different gas mixture plasmas for various microelectronic applications,, Scientific reports, vol. 7, no. 1, pp.1-9, (2017).

DOI: 10.1038/s41598-017-04389-y

[7] J. Pernot et al., Electrical transport properties of aluminum-implanted 4H–SiC,, Journal of applied physics, vol. 98, no. 2, p.023706, (2005).

DOI: 10.1063/1.1978987
