A Simplified Method for Extracting Contact Resistivity Using the Circular Transmission Line Model

Abstract:

To ensure maximum device current is supplied through a vertical device having a backside ohmic contact, the specific contact resistivity, ρ_c, must be well characterized as it constitutes a portion of the device resistance. While there are multiple approaches to deduce ρ_c, the transmission line model (TLM) remains a convenient choice because of its simplicity in terms of fabrication, measurement, and analysis. For thick substrates where mesa isolation is impractical, the circular transmission line model (CTLM) is an attractive path. In this study we propose an additional restriction on the CTLM design such that the ρ_c is readily extracted from a simple linear regression just as is the case in a linear TLM. We demonstrate the simplified method by extracting ρ_c of an ohmic contact to the c-face of 4H-SiC substrate.
