A 1cm × 1cm, 5kV, 100A, 4H-SiC Thyristor Chip for High Current Modules

Abstract:

We report on the development of the first 1 cm x 1 cm SiC Thyristor chip capable of blocking 5 kV. This demonstrates the present quality of the SiC substrate and epitaxial material. A forward drop of 4.1 V at 100 A and 25°C has been measured. The turn-on delay is found to be a strong function of the gate current. At a gate current of 0.5 A, a turn-on delay of 250 ns is observed for an anode to cathode current of 200 A. The turn-on delay reduces to 72 ns for an IG = 1.5 A. The turn-on rise time is a strong function of the anode to cathode voltage, VAK. At VAK =230 V, the turn-on rise-time is 300 ns for IAK =200 A. The rise-time reduces to 26 ns for VAK = 500 V.

You might also be interested in these eBooks

Silicon Carbide and Related Materials 2005

View Preview

Info:

Periodical:

Materials Science Forum (Volumes 527-529)

Pages:

1397-1400

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.527-529.1397

Citation:

Cite this paper

Online since:

October 2006

Authors:

Anant K. Agarwal, Sumi Krishnaswami, Ben Damsky, Jim Richmond, Craig Capell, John W. Palmour, Sei Hyung Ryu

Keywords:

High Power, High Voltage (HV), Switch, Thyristor, Turn-On

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Anant Agarwal, Mrinal Das, Sumi Krishnaswami, John Palmour, James Richmond and SeiHyung Ryu: Mat. Res. Soc. Symp. Proc. Vol. 815 (2004), p.243.

Google Scholar

[2] A. R. Powell, et al.: Mat. Res. Soc. Symp. Proc. Vol. 815 (2004), p.3.

Google Scholar

[3] S. B. Bayne, C. W. Tipton, T. Griffin, C. J. Scozzie, B. Geil, A. K. Agarwal, and J. Richmond: IEEE Electron Dev. Lett. Vol. 23 (2002), p.318.

DOI: 10.1109/led.2002.1004221

Google Scholar

[4] Y. Sugawara, D. Takayama, K. Asano, A. Agarwal, S. Ryu, J. Palmour, and S. Ogata: Proceedings of the 16th International Symposium on Power Semiconductor Devices & IC's, Kitakyushu, Japan, May 24-27 (2004), p.289.

DOI: 10.1109/wct.2004.240155

Google Scholar

[5] B. Li, L. Cao and J. H. Zhao: IEEE Electron Dev. Lett., Vol. 20 (1999), p.219.

Google Scholar

[6] Anant K. Agarwal, Ben Damsky, James Richmond, Sumi Krishnaswami, Craig Capell, SeiHyung Ryu and John W. Palmour: Proceedings of the 17th International Symposium on Power Semiconductor Devices & IC's, Santa Barbara, Ca, May 23-26 (2005).

Google Scholar
