4H-SiC Single Photon Avalanche Diode for 280nm UV Applications

Jun  Hu; Xiao Bin Xin; Peter Alexandrov; Jian Hui Zhao; Brenda L. VanMil; D. Kurt Gaskill; Kok Keong Lew; Rachael L. Myers-Ward; Charles R. Eddy

doi:10.4028/www.scientific.net/MSF.600-603.1203

Paper Titles

12 kV 4H-SiC p-IGBTs with Record Low Specific On-Resistance
p.1187

Design, Simulation, and Characterization of High-Voltage SiC p-IGBTs
p.1191

SiC Based Optically-Gated High-Power Solid-State Switch for Pulsed-Power Application
p.1195

Hydrogen Gas Sensors Fabricated on Atomically Flat 4H-SiC Webbed Cantilevers
p.1199

4H-SiC Single Photon Avalanche Diode for 280nm UV Applications
p.1203

Avalanche Multiplication and Impact Ionisation in Separate Absorption and Multiplication 4H-SiC Avalanche Photodiodes
p.1207

Observation of Luminescence from Defects in 4H-SiC APDs Operating in Avalanche Breakdown
p.1211

Schottky Barrier Lowering in 4H-SiC Schottky UV Detector
p.1215

The Influence of Radiation Defects on the Charge Transport in SiC Nuclear Detectors in Conditions of Elevated Temperatures and Deep Compensation of the Conductivity
p.1219

HomeMaterials Science ForumMaterials Science Forum Vols. 600-6034H-SiC Single Photon Avalanche Diode for 280nm UV...

4H-SiC Single Photon Avalanche Diode for 280nm UV Applications

Abstract:

This paper reports a 4H-SiC single photo avalanche diode (SPAD) operating at the solar blind wavelength of 280 nm. The SPAD has an avalanche breakdown voltage of 114V. At 90% and 95% of the breakdown voltage, the SPAD shows a low dark current of 57.2fA and 159fA, respectively. The quantum efficiency of 29.8% at 280nm and <0.007% at 400nm indicates a high UV-to-visible rejection ratio of >4300. Single photon counting measurement at 280nm shows that a single photon detection efficiency of 2.83% with a low dark count rate of 22kHz is achieved at the avalanche breakdown voltage of 116.8V.
