Pulse Current Characterization of SiC GTO Thyristors

Abstract:

With a focus on pulsed power applications, this paper presents results of the pulse current characterization of GTO thyristors developed and fabricated within a previous ISL funded project. Limited by the pulse current capability of the bonding wire connection, the devices demonstrated to handle a peak current of up to 6 kA/cm2 (about 20 µs FWHM). Pulse tests of Al wires indicate that two 50 µm wires should be sufficient to test a 1 mm2 device up to a peak current of 30 kA/cm2.

You might also be interested in these eBooks

Silicon Carbide and Related Materials 2010

View Preview

Info:

Periodical:

Materials Science Forum (Volumes 679-680)

Pages:

682-685

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.679-680.682

Citation:

Cite this paper

Online since:

March 2011

Authors:

Sigo Scharnholz, Bertrand Vergne, Jens Peter Konrath, Gontran Pâques, Volker Zorngiebel

Keywords:

GTO, Pulsed Power, Thyristor, Wire Bonding

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] D. Peters, W. Bartsch, B. Thomas and R. Sommer, 6. 5 kV SiC PiN diodes with improved forward characteristics, Mater. Sci. Forum Vol. 645-648 (2010), p.901.

DOI: 10.4028/www.scientific.net/msf.645-648.901

Google Scholar

[2] A. Agarwal, C. Capell, V. Temple, H. O. O'Brien et al., 9 kV, 1cm´1cm SiC super GTO technology development for pulsed power, Proc. 17th IEEE Pulsed Power Conf. (2009), p.264.

DOI: 10.1109/ppc.2009.5386305

Google Scholar

[3] E. Spahn, K. Sterzelmeier, C. Gauthier-Blum, et al., 50-kJ ultracompact pulsed-power supply unit for active protection launcher systems, IEEE Trans. on Magnetics 45(1) (2009), p.462.

DOI: 10.1109/tmag.2008.2008527

Google Scholar

[4] S. Scharnholz, V. Zorngiebel, P. Brosselard, D. Planson et al., Electrical characterization of 4H-SiC GTO-Thyristors realized by ISL, Proc. of SAEI-EPF, Toulouse, France (2004).

DOI: 10.4028/www.scientific.net/msf.457-460.1129

Google Scholar

[5] V. Zorngiebel, Entwicklung von SiC-Thyristoren für das Schalten hoher gepulster Leistungen, PhD thesis, RWTH Aachen, Schaker Verlag Aachen, (2003).

Google Scholar

[6] P. Brosselard, D. Planson, S. Scharnholz, C. Raynaud, V. Zorngiebel, et al., Edge termination strategies for a 4 kV 4H-SiC thyristor, Solid-State Electronics 50 (2006), p.1183.

DOI: 10.1016/j.sse.2006.05.016

Google Scholar
