Ohmic Contact for Silicon Carbide by Carbon Nanotubes

Abstract:

The electrical contact properties of silicon carbide (SiC) and carbon nanotubes (CNTs) were measured by conductive atomic force microscopy (C-AFM). A CNT forest was synthesized by SiC surface decomposition. Trenches, which electrically separate the conduction area, were fabricated using a focused ion beam (FIB) without a cover layer, and the resistance of each island was measured by C-AFM. From the dependence of the resistance on the CNT forest island size, the contact resistance between the CNTs and the SiC substrate was measured. By varying the dopant density in the SiC substrate, the Schottky barrier height was evaluated to be ~0.5 eV. This is slightly higher than a previously reported result obtained from a similar setup with a metal covering the CNT forest. We assumed that the damaged region existed in the islands, which is due to the trench formation by the FIB. The commensurate barrier height was obtained with the length of the damaged region assumed to be ~3 μm. Here, we could estimate the resistivity of a CNT/SiC interface without a cover layer. This indicates that a CNT forest on SiC is useful as a brief contact electrode.

You might also be interested in these eBooks

Silicon Carbide and Related Materials 2015

View Preview

Info:

Periodical:

Materials Science Forum (Volume 858)

Pages:

561-564

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.858.561

Citation:

Cite this paper

Online since:

May 2016

Authors:

Masafumi Inaba*, Kazuma Suzuki, Yu Hirano, Wataru Norimatsu, Michiko Kusunoki, Hiroshi Kawarada

Keywords:

Carbon Nanotube, Contact Resistivity, Schottky Barrier, Silicon Carbide (SiC)

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] W. Norimatsu, C. Kawai and M. Kusunoki, INTECH Open Access Publisher, (2011).

Google Scholar

[2] M. Inaba, K. Suzuki, M. Shibuya, C. Lee, Y. Masuda, N. Tomatsu, W. Norimatsu, A. Hiraiwa, M. Kusunoki, and H. Kawarada, Appl. Phys. Lett. 106, 123501 (2015).

DOI: 10.1063/1.4916248

Google Scholar

[3] W. Norimatsu, T. Maruyama, K. Yoshida, K. Takase, and M. Kusunoki, Appl. Phys. Express 5, 10 (2012).

Google Scholar

[4] Z. Cambaz, G. Yushin, S. Osswald, V. Mochalin, and Y. Gogotsi, Carbon 46, 841 (2008).

DOI: 10.1016/j.carbon.2008.02.013

Google Scholar

[5] C. Crowell and V. Rideout, Solid-State Electron. 12, 89 (1969).

Google Scholar

[6] M. Kusunoki and H. Kato, Appl. Surf. Sci. 254, 1 (2007).

Google Scholar
