Impact of Phosphorus Implantation on the Electrical Properties of SiO₂/4H-SiC Interfaces Annealed in N₂O

Abstract:

In this work, the combined effect of a shallow phosphorus (P) pre-implantation and of a nitridation annealing in N₂O on the properties of the SiO₂/4H-SiC interface has been investigated. The peak carrier concentration and depth extension of the electrically active dopants introduced by the nitridation and by the combination of P pre-implantation and nitridation were determined by high resolution scanning capacitance microscopy (SCM). Macroscopic capacitance-voltage (C-V) measurements on metal oxide semiconductor (MOS) capacitors and nanoscale C-V analyses by SCM allowed to quantify the electrical effect of the donors introduced underneath the SiO₂/4H-SiC interface. Phosphorous pre-implantation and subsequent high temperature electrical activation has been shown not only to produce an increased doping in the 4H-SiC surface region but also a better homogeneity of surface potential with respect to the use of N₂O annealing only.

You might also be interested in these eBooks

Silicon Carbide and Related Materials 2015

View Preview

Info:

Periodical:

Materials Science Forum (Volume 858)

Pages:

701-704

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.858.701

Citation:

Cite this paper

Online since:

May 2016

Authors:

Patrick Fiorenza*, Salvatore Di Franco, Filippo Giannazzo, Simone Rascunà, Mario Saggio, Fabrizio Roccaforte

Keywords:

Ion Implantation, MOS, Scanning Capacitance Microscopy, Surface Potential

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] V.V. Afanas'ev, et al, J. Phys.: Condens. Matter 16, (2004) S1839–S1856.

Google Scholar

[2] H. Li, S. Dimitrijev, H. B. Harrison, D. Sweatman, Appl. Phys. Lett. 70 (1997) (2028).

Google Scholar

[3] D. Okamoto, et al, IEEE Electron Dev. Lett. 31 (2010) 710.

Google Scholar

[4] P. Fiorenza, L.K. Swanson, M. Vivona, F. Giannazzo, C. Bongiorno, A. Frazzetto, F. Roccaforte, Appl Phys A 115 (2014) 333.

DOI: 10.1007/s00339-013-7824-y

Google Scholar

[5] T. Umeda, K. Esaki, R. Kosugi, K. Fukuda, T. Ohshima, N. Morishita, and J. Isoya, Appl. Phys. Lett. 99 (2011) 142105.

DOI: 10.1063/1.3644156

Google Scholar

[6] L.K. Swanson, P. Fiorenza, F. Giannazzo, A. Frazzetto, and F. Roccaforte, Appl. Phys. Lett. 101 (2012) 193501.

Google Scholar

[7] A. Mikhaylov, T. Sledziewski, A. Afanasyev, V. Luchinin, S. Reshanov, A. Schöner and M. Krieger, Mater. Sci. Forum 806 (2015) 133-138.

DOI: 10.4028/www.scientific.net/msf.806.133

Google Scholar

[8] A. Modic, G. Liu, A. C. Ahyi, Y. Zhou, P. Xu, M. C. Hamilton, J. R. Williams, L. C. Feldman, and Sarit Dhar; IEEE Electron Dev. Lett. 35 (2014) 894.

DOI: 10.1109/led.2014.2336592

Google Scholar

[9] D. Okamoto, et al., IEEE Elec. Dev. Lett. 35 (2014) 1176.

Google Scholar

[10] P. Fiorenza, F. Giannazzo, M. Vivona, A. La Magna, and F. Roccaforte, Appl. Phys. Lett. 103 (2013) 153508.

Google Scholar
