Comparison of 2.5D and 3D Simulation Methods for Limiting Electrode Debiasing of 4H-SiC Interdigitated Devices

Abstract:

This paper assesses the 2.5D simulation method for limiting the electrodes debiasing of interdigitated devices. This method uses both spice and finite element method simulations where a resistance grid models the electrodes and a 2D finite elements structure models the device. A lateral 4H-SiC PiN diode has been selected for this study. In order to assess this method, 2.5D simulation method has been compared to 3D simulations.
