Short-Circuit Robustness Testing of SiC MOSFETs

Abstract:

This paper presents electrical results for two different commercial devices and one prototype 1.2 kV SiC power MOSFET device subject to short-circuit (SC) stress. Two failure modes were observed among the devices tested, with one mode of failure resulting in catastrophic device destruction and the other resulting in permanent damage of the insulating gate dielectric manifested as a leakage current of 400 mA. Short-circuit pulses of increasing time duration caused a reduction in the gate-to-source voltage toward the falling edge of the pulse. This phenomenon is a precursor to failure of SiC MOSFETs under SC stress, but this reduction in V_GS is not known to occur in silicon-based devices. The measured short-circuit withstand times for commercial devices from group A and B MOSFETs were 8 us and 12 us, respectively. MOSFET-C devices had a withstand time of 7 us. A larger chip size improves robustness even for large values of peak short-circuit current.

You might also be interested in these eBooks

Silicon Carbide and Related Materials 2016

View Preview

Info:

Periodical:

Materials Science Forum (Volume 897)

Pages:

525-528

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.897.525

Citation:

Cite this paper

Online since:

May 2017

Authors:

Ronald Green, Damian P. Urciuoli, Aivars J. Lelis

Keywords:

MOSFET, Ruggedness, SC Failure Modes, Short-Circuit (SC), Silicon Carbide (SiC)

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] A. Awwad, and S. Dieckerhoff, Short-Circuit Evaluation and Overcurrent Protection for SiC Power MOSFETs, 17th European Power Electronics and Applications Conference, (2015).

DOI: 10.1109/epe.2015.7311701

Google Scholar

[2] Test Methods for Semiconductor Devices, MIL-STD-750E, (2006).

Google Scholar

[3] A. Castellazzi, A. Fayyaz, G. Romano, L. Yang, M. Riccio, and A. Irace, SiC Power MOSFETs performance, robustness and technology maturity, Microelectronics Reliability, 58 (2016) 164-178.

DOI: 10.1016/j.microrel.2015.12.034

Google Scholar

[4] G. Romano, A. Fayyaz, M. Riccio, L. Maresca, G. Greglio, A. Castellazzi, and A. Irace, A Comprehensive Study of Short-Circuit Ruggedness of Silicon Carbide Power MOSFETs, IEEE J. of Emerging and Selected Topics in Power Electronics, 163 (2016).

DOI: 10.1109/jestpe.2016.2563220

Google Scholar

[5] C. Chen, D. Labrousse, S. Lefebvre, M. Petit, C. Buttay, and H. Morel, Study of short-circuit robustness of SiC MOSFETs, analysis of the failure modes and comparison with BJTs, Microelectron. Reliab., 55, (2015) 1708-1713.

DOI: 10.1016/j.microrel.2015.06.097

Google Scholar

[6] Y. Nakao, S. Wantanabe, N. Miura, M. Imaizumi, and T. Oomori, Investigation into Short-Circuit Ruggedness of 1. 2 kV 4H-SiC MOSFETs, Mat. Sci. Forum, Vols. 600-603, (2009) 1123-1126.

DOI: 10.4028/www.scientific.net/msf.600-603.1123

Google Scholar
