Negative Bias Temperature Instability on Subthreshold Swing of SiC MOSFET

Abstract:

The NBTI characteristics of SiC MOSFET were studied by the subthreshold swing. The subthreshold swing was found to be very sensitive to the starting bias of transfer curve. The increase of subthreshold swing for MOSFET with poor oxide reached 400% when the starting bias was-15V. The increase of subthreshold swing was caused by enhanced hole trapping which could be explained by the mechanism of positively charged interface states assisted hole trapping. The increase of subthreshold swing for MOSFET with improved gate oxide was reduced to about 40% when the starting bias was-20V and the value approached saturation for starting biases more negative than-10V, which can also be explained by the proposed mechanism. The increase of subthreshold swing for MOSFET with improved oxide was not sensitive to the temperature. The increase of subthreshold swing at 175°C was only 5%~7% higher than that at room temperature.

You might also be interested in these eBooks

Silicon Carbide and Related Materials 2016

View Preview

Info:

Periodical:

Materials Science Forum (Volume 897)

Pages:

533-536

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.897.533

Citation:

Cite this paper

Online since:

May 2017

Authors:

Cheng Tyng Yen*, Hsiang Ting Hung, Chien Chung Hung, Lurng Shehng Lee, Chwan Ying Lee, Yao Feng Huang, Fu Jen Hsu, Tzong Liang Chen

Keywords:

Hole Trapping, NBTI, Positive Charge, Subthreshold Swing, Threshold Voltage Instability

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] J. Rozen, Tailoring Oxide/Silicon Carbide Interfaces NO Annealing and Beyond, in Y. Hijikata (Eds. ) Physics and Technology of Silicon Carbide Devices, InTech, (2012).

DOI: 10.5772/54396

Google Scholar

[2] H. Yano, N. Kanafuji, A. Osawa, T. Hatayama, T. Fuyuki, IEEE Trans. Electron Devices, 62, 324 (2015).

DOI: 10.1109/ted.2014.2358260

Google Scholar

[3] C. T. Yen, H. T. Hung, C. C. Hung, C. Y. Lee, H. Y. Lee, L. S. Lee, Y. F. Huang, C. Y. Cheng, P. J. Chuang, F. J. Hsu, Mater. Sci. Forum (2016), 595-598.

DOI: 10.4028/www.scientific.net/msf.858.595

Google Scholar

[4] C. T. Yen, C. C. Hung, H. T. Hung, C. Y. Lee, L. S. Lee, Y. F. Huang, F. J. Hsu, Appl. Phys. Lett. 108, 012106 (2016).

Google Scholar

[5] A. Lelis, R. Green, D. Habersat and M. El, IEEE Trans. Electron Devices, 62, 316 (2015).

Google Scholar
