Prediction of High-Density and High-Mobility Two-Dimensional Electron Gas at Al_xGa_1-xN/4H-SiC Interface

Abstract:

This work presents theoretical demonstration of two-dimensional electron gas (2DEG) at the interface between Al_0.2Ga_0.8N and 4H-SiC, based on the self-consistent solution of Schrödinger–Poisson equations. High sheet carrier density of 1.1×10¹³cm^-2 was obtained in the Al_0.2Ga_0.8N/4H-SiC heterostructure, which is comparable to the electron concentration in Al_0.2Ga_0.8N/GaN heterostructure. The current–voltage characteristics of a high-electron-mobility transistor (HEMT), based on the Al_0.2Ga_0.8N/4H-SiC heterostructure, show a saturated drain current of 1.5 A/mm at the gate voltage of 2 V and the transconductance of 194 mS/mm at -3.95 V. In spite of interface-roughness scattering and phonon scattering, the 2DEG at the Al_xGa_1-xN/4H-SiC interface exhibits high electron mobility values of 3365 cm²/ (V·s) at 77K and 1120 cm²/ (V·s) at 300K. These results indicate that Al_xGa_1-xN/4H-SiC heterostructure can significantly improve the mobility of SiC based power switching devices.
