Prolonged 500°C Operation of 100+ Transistor Silicon Carbide Integrated Circuits

Abstract:

This report describes more than 5000 hours of successful 500 °C operation of semiconductor integrated circuits (ICs) with more than 100 transistors. Multiple packaged chips with two different 4H-SiC junction field effect transistor (JFET) technology demonstrator circuits have surpassed thousands of hours of oven-testing at 500 °C. After 100 hours of 500 °C burn-in, the circuits (except for 2 failures) exhibit less than 10% change in output characteristics for the remainder of 500 °C testing. We also describe the observation of important differences in IC materials durability when subjected to the first nine constituents of Venus-surface atmosphere at 9.4 MPa and 460 °C in comparison to what is observed for Earth-atmosphere oven testing at 500 °C.

You might also be interested in these eBooks

Silicon Carbide and Related Materials 2017

View Preview

Info:

Periodical:

Materials Science Forum (Volume 924)

Pages:

949-952

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.924.949

Citation:

Cite this paper

Online since:

June 2018

Authors:

David J. Spry, Philip G. Neudeck*, Dorothy Lukco, Liang Yu Chen, Michael J. Krasowski, Norman F. Prokop, Carl W. Chang, Glenn M. Beheim

Keywords:

High Temperature, Integrated Circuit (IC), JFET, Random Access Memory, Venus

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] P. G. Neudeck, SiC Integrated Circuit Platforms for High-Temperature Applications, in: J. Cressler, H. Mantooth (Eds.), Extreme Environment Electronics, CRC Press, 2013, pp.225-232.

DOI: 10.1201/b13001-20

Google Scholar

[2] C.-M. Zetterling, Extreme Environment SiC Integrated Circuits, ICSCRM 2017, TU.D1.4.

Google Scholar

[3] D. J. Spry, et al., Mat. Sci. Forum 600-603 (2008) 1079-1082.

Google Scholar

[4] D. J. Spry, et al., Mat. Sci. Forum 828 (2016) 908-912.

Google Scholar

[5] D. J. Spry, et al., Mat. Sci. Forum 828 (2016) 1112-1116.

Google Scholar

[6] D. J. Spry, et al., IEEE Electron Device Lett. 37 (2016) 625-628.

Google Scholar
