Novel Method for Evaluation of Negative Bias Temperature Instability of SiC MOSFETs

Abstract:

The material properties of SiC make SiC power devices a superior alternative to the conventional Si power devices. However, the reliability of the gate oxide has been a major concern, limiting the adoption of SiC power MOSFETs as the power semiconductor of choice in applications which demand a high reliability. The threshold voltage (V_TH) shift caused by Bias Temperature Instability (BTI) has focused the attention of different researchers, with multiple publications on this topic. This paper presents a novel method for evaluating the threshold voltage shift due to negative gate bias and its recovery when the gate bias stress is removed. This method could enable gate oxide reliability assessment techniques and contribute to new qualification methods.

• Periodical: Materials Science Forum (Volume 963)
• Pages: 749-752
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.963.749
• Online since: July 2019
• Authors: Jose Ortiz-Gonzalez*, Olayiwola Alatise, Philip Andrew Mawby
• Keywords: Gate Oxide, Negative Bias Temperature Instability (NBTI), SiC MOSFET

References

[1] T. Aichinger, G. Rescher, and G. Pobegen, Threshold voltage peculiarities and bias temperature instabilities of SiC MOSFETs, Microelectron. Rel., vol. 80, (2018), pp.68-78.

DOI: 10.1016/j.microrel.2017.11.020

[2] A. J. Lelis, R. Green, and D. B. Habersat, SiC MOSFET threshold-stability issues,, Mater. Sci. in Semiconductor Processing, vol. 78, (2018), pp.32-37.

DOI: 10.1016/j.mssp.2017.11.028

[3] K. Puschkarsky et al., Understanding BTI in SiC MOSFETs and its impact on circuit operation,, IEEE Trans. on Dev. and Mater. Rel., vol. 18, no. 2, (2018), pp.144-153.

DOI: 10.1109/tdmr.2018.2813063

[4] S. Jahdi et al., Temperature and Switching Rate Dependence of Crosstalk in Si-IGBT and SiC Power Modules,, IEEE Trans. on Ind. Electron., vol. 63, no. 2, (2016), pp.849-863.

DOI: 10.1109/tie.2015.2491880

[5] J. Hu et al., Robustness and Balancing of Parallel-Connected Power Devices: SiC Versus CoolMOS,, IEEE Trans. on Ind. Electron., vol. 63, no. 4, (2016), pp.2092-2102.

DOI: 10.1109/tie.2015.2500187

[6] D. B. Habersat, A. J. Lelis, and R. Green, Measurement considerations for evaluating BTI effects in SiC MOSFETs,, Microelectron. Rel., vol. 81, (2018), pp.121-126.

DOI: 10.1016/j.microrel.2017.12.015

[7] G. Rescher et al., Preconditioned BTI on 4H-SiC: Proposal for a Nearly Delay Time-Independent Measurement Technique,, IEEE Trans. on Electron Dev., vol. 65, no. 4, (2018), pp.1419-1426.

DOI: 10.1109/ted.2018.2803283

[8] J. Lutz et al. Semiconductor Power Devices. Physics, Characteristics, Reliability,, 2nd Ed., Springer International Publishing, (2018).

[9] A. Ortiz-Conde et al., Revisiting MOSFET threshold voltage extraction methods,, Microelectron. Rel., vol. 53 (2013), pp.90-104.
