Analytical Modelling of the Quasi-Static Operation of a Monolithically Integrated 4H-SiC Circuit Breaker Device

Abstract:

In this work, an analytical model describing the quasi-static operation of a monolithically integrated SiC solid-state circuit breaker (SSCB) device is rederived and refined. This SSCB is based on a 4H-SiC JFET technology offering a self-sensed blocking mechanism. The proposed model is solely based on physical parameters including the SSCB design parameters. With respect to the refinement, the proposed model is not limited to one-sided pn-junctions, considers incomplete ionization of dopants, and is able to represent breakdown characteristics. In this regard, the JFET gate breakdown characteristics are derived taking thermionic emission, space-charge-limited current and impact ionization into account. To calculate the SSCB output characteristics, a bisection-based optimization algorithm is applied carefully considering individual JFET operating states.

By email View Pdf

You might also be interested in these eBooks

20th International Conference on Silicon Carbide and Related Materials (ICSCRM 2023)

View Preview

Solid-State Power Devices: Circuitry and Characterizations

View Preview

Info:

Periodical:

Solid State Phenomena (Volume 360)

Pages:

111-118

DOI:

https://doi.org/10.4028/p-EkvC4B

Citation:

Cite this paper

Online since:

August 2024

Authors:

Norman Boettcher*, Mathias Rommel, Johann Tobias Erlbacher

Keywords:

4H-SiC, Analytical Model, Circuit Breaker, Gate Breakdown, JFET (Junction Field-Effect Transistor), Self-Sensed, SSCB

Export:

RIS, BibTeX

Permissions:

Creative Commons CC BY 4.0

Citation:

* - Corresponding Author

References

[1] R. Rodrigues, et al., IEEE Transactions on Power Electronics, vol. 36, no. 1, pp.364-377, Jan. 2021.

DOI: 10.1109/TPEL.2020.3003358

Google Scholar

[2] D. He, et al., IEEE Journal of Emerging and Selected Topics in Power Electronics, vol. 7, no. 3, pp.1556-1565, Sept. 2019.

DOI: 10.1109/JESTPE.2019.2906661

Google Scholar

[3] N. Boettcher and T. Erlbacher, IEEE Electron Device Letters, vol. 42, no. 10, pp.1516-1519, Oct. 2021.

DOI: 10.1109/LED.2021.3102935

Google Scholar

[4] N. Boettcher, et al, IEEE International Symposium on Power Semiconductor Devices and ICs, Vancouver, BC, Canada, 2022, pp.261-264.

DOI: 10.1109/ISPSD49238.2022.9813628

Google Scholar

[5] N. Boettcher, et al. IEEE European Conference on Power Electronics and Applications (EPE'22 ECCE Europe), Hanover, Germany, 2022, pp. P.1-P.9.

Google Scholar

[6] N. Boettcher and T. Erlbacher, IEEE Workshop on Wide Bandgap Power Devices and Applications Asia, Suita, Japan, 2020, pp.1-6.

DOI: 10.1109/WiPDAAsia49671.2020.9360279

Google Scholar

[7] Kimoto, T. and Cooper, J.A. (2014). Fundamentals of Silicon Carbide Technology.

DOI: 10.1002/9781118313534

Google Scholar

[8] J.L. Chu, G. Persky, S.M. Sze; Journal of Applied Physics, August 1972; 43 (8): 3510–3515.

DOI: 10.1063/1.1661745

Google Scholar

[9] T. Takamori, et al., IEEE Transactions on Industry Applications, June 2023 (early access).

DOI: 10.1109/TIA.2023.3288856

Google Scholar
