Formation Mechanism and Complex Faulting Behavior of a BPD Loop in 180 μm Thick 4H-SiC Epitaxial Layer

Abstract:

4H-SiC with 180 μm epilayer was subjected to UV exposure. Stacking fault expanded from basal plane dislocation (BPD) loop generated during growth in the epilayer was observed by UV Photoluminescence Imaging (UVPL) and X-ray Topograph (XRT) techniques. Interactions between partial dislocation, emanating from the BPD loop and gliding via recombination-enhanced dislocation glide mechanism, and threading screw/mix dislocations are detected and analyzed, where stacking faults migrate to different basal plane after the interactions. Such migration increases the faulted volume that can severely degrade reliability and performance of high power SiC devices by increasing reverse leakage current and on-state resistance and could eventually lead to device failure.

By email View Pdf

You have full access to the following eBook

Read eBook

Info:

Periodical:

Solid State Phenomena (Volume 375)

Pages:

35-41

DOI:

https://doi.org/10.4028/p-I5U9fS

Citation:

Cite this paper

Online since:

September 2025

Authors:

Ze Yu Chen*, Nadeemullah A. Mahadik, Michael Dudley, Balaji Raghothamachar, David A. Scheiman, Robert E. Stahlbush, Young Sang Kim, Michael W. Owen

Keywords:

4H-SiC, Partial Dislocation Dipole, Stacking Fault, UV Photoluminescence Imaging, X-Ray Topography

Export:

RIS, BibTeX

Permissions:

Creative Commons CC BY 4.0

Citation:

* - Corresponding Author

References

[1] A.A. Lebedev and V.E. Chelnokov, Semiconductors 33, 999–1001 (1999).

Google Scholar

[2] P. Luo and S. N. E. Madathil, IEEE Transactions on Electron Devices, 67 5621-5627 (2020)

Google Scholar

[3] H. Tsuchida, I. Kamata, T. Miyazawa, M. Ito, X. Zhang and M. Nagano, Materials Science in Semiconductor Processing, 78, 2 (2018)

Google Scholar

[4] N. A. Mahadik, R.E. Stahlbush, M. Dudley, B. Raghothamachar, M. Hinojosa, A. Lelis and W. Sung, Scripta Materialia 235, 115598 (2023)

DOI: 10.1016/j.scriptamat.2023.115598

Google Scholar

[5] J.P. Bergman, H. Lendenmann, PA. Nilsson, U. Lindefelt and P. Skytt ., Mater. Sci. Forum 353–356, 299–302 (2001)

DOI: 10.4028/www.scientific.net/msf.353-356.299

Google Scholar

[6] A. Galeckas, J. Linnros and P. Pirouz, Appl. Phys. Lett. 81, 883–885 (2002)

Google Scholar

[7] N. Zhang, Y. Chen, Y. Zhang, M. Dudley and R. E. Stahlbush, Appl. Phys. Lett. 94, 122108 (2009)

Google Scholar

[8] N. A. Mahadik, R. E. Stahlbush and W. Sung, J. Appl. Phys. 131, 225702 (2022)

Google Scholar

[9] R. E. Stahlbush, K. X. Liu, Q. Zhang, and J. J. Sumakeris, Mater. Sci. Forum 556-557, 295 (2007)

Google Scholar

[10] D. Hull and D.J. Bacon, Intersection of Dislocations, in: Fifth Edition, Introduction to Dislocations, Elsevier, 2011, pp.137-139.

Google Scholar

[11] Y. Chen, M. Dudley, K. X. Liu, R. E. Stahlbush, Appl. Phys. Lett. 90, 171930, (2007)

Google Scholar

[12] A. Iijima, I. Kamata, H. Tsuchida, J. Suda and T. Kimoto, Philosophical Magazine,97:30, 2736-2752, (2017)

DOI: 10.1080/14786435.2017.1350788

Google Scholar

[13] D. Hull and D.J. Bacon, Intersection of Dislocations, in: Fifth Edition, Introduction to Dislocations, Elsevier, 2011, pp.75-79.

Google Scholar

[14] C. S. Hartley, and J. P. Hirth, Acta Metallurgica 13.2 79-88. (1965)

Google Scholar

[15] D. Caillard, Modelling and Simulation in Materials Science and Engineering 32.3: 035027. (2024)

Google Scholar
