Dynamics of Stacking Fault Expansion in H⁺ Implanted SiC-MOSFETs

Abstract:

Bipolar degradation is a well-known issue when using body diodes in SiC-MOSFETs. Recent studies suggest that H⁺ (proton) implantation can effectively inhibit this degradation, but demonstrations on its suppression are still limited. Therefore, in this study, we have experimentally demonstrated how the expansion of Shockley-type stacking faults (SSFs) is suppressed by proton implantation. We fabricated a vertical SiC-MOSFET, in which protons were implanted into the middle depth of the drift layer. We then subjected the body diode to continuous current stress and performed photoluminescence (PL) analysis. Detailed PL image and emission spectral analysis of SSFs revealed that the proton-implanted layer can function as a recombination-enhancing layer during bipolar operation. Furthermore, it can be formed at any depth within the drift layer by controlling the energy, offering a significant advantage in the design of SiC-MOSFETs.

By email View Pdf

You have full access to the following eBook

Read eBook

Info:

Periodical:

Solid State Phenomena (Volume 376)

Pages:

33-40

DOI:

https://doi.org/10.4028/p-MI3pHl

Citation:

Cite this paper

Online since:

September 2025

Authors:

Kazuya Ishibashi*, Naoki Shikama, Hiroki Niwa, Takanori Tanaka, Hiroyuki Amishiro, Akifumi Imai, Katsutoshi Sugawara, Yasuhiro Kagawa, Akihiko Furukawa

Keywords:

Bipolar Degradation, Body Diode, MOSFET, Proton Implantation, Stacking Fault

Export:

RIS, BibTeX

Permissions:

Creative Commons CC BY 4.0

Citation:

* - Corresponding Author

References

[1] A. Galeckas, J. Linnros and P. Pirouz, Appl. Phys. Lett. 81, 883 (2002).

Google Scholar

[2] M. Skowronski and S. Ha, J. Appl. Phys. 99, 011101 (2006).

Google Scholar

[3] A. Agarwal, H. Fatima, S. Haney and S. Ryu, IEEE Electron Device Lett. 28, 587 (2007).

Google Scholar

[4] T. Tawara, T. Miyazawa, M. Ryo, M. Miyazato, T. Fujimoto, K. Takenaka, S. Matsunaga, M. Miyajima, A. Otsuki, Y. Yonezawa, T. Kato, H. Okumura, T. Kimoto and H. Tsuchida, J. Appl. Phys. 120, 115101 (2016).

DOI: 10.1063/1.4962717

Google Scholar

[5] M. Kato, O. Watanabe, T. Mii, H. Sakane and S. Harada, Sci. Rep. 12, 18790 (2022).

Google Scholar

[6] S. Harada, T. Mii, H. Sakane and M. Kato, Sci. Rep. 12, 13542 (2022).

Google Scholar

[7] A. Tanaka, H. Matsuhata, N. Kawabata, D. Mori, K. Inoue, M. Ryo, T. Fujimoto, T. Tawara, M. Miyazato, M. Miyajima, K. Fukuda, A. Ohtsuki, T. Kato, H. Tsuchida, Y. Yonezawa and T. Kimoto, J. Appl. Phys. 119, 095711 (2016).

DOI: 10.1063/1.4943165

Google Scholar

[8] C. Ota, J. Nishio and R. Iijima, J. Electron. Mater. 50, 6504 (2021).

Google Scholar

[9] A. Iijima, I. Kamata, H. Tsuchida, J. Suda and T. Kimoto, Philos. Mag. 97, 2736 (2017).

Google Scholar

[10] I. Kamata, X. Zhang and H. Tsuchida, Appl. Phys. Lett. 97, 172107 (2010).

Google Scholar

[11] N. A. Mahadik, R. E. Stahlbush, J. D. Caldwell and K. D. Hobart, Mater. Sci. Forum 717-720, 391 (2001).

Google Scholar

[12] T. Miyanagi, H. Tsuchida, I. Kamata, T. Nakamura, K. Nakayama, R. Ishii and Y. Sugawara, Appl. Phys. Lett. 89, 062104 (2006).

Google Scholar

[13] J. D. Caldwell, R. E. Stahlbush, K. D. Hobart, O. J. Glembocki and K. X. Liu, Appl. Phys. Lett. 90, 143519 (2007).

Google Scholar

[14] J. D. Caldwell, K. X. Liu, M. J. Tadjer, O. J. Glembocki, R. E. Stahlbush, K. D. Hobart and F. Kub, J. Electron. Mater. 36, 318 (2007).

Google Scholar
