Achieving Low Dit (~5×1010eV-1cm-2), Competitive JG (~ 5×10-10 A cm-2) Performance and Enhanced Post-Stress Flatband Voltage Stability Using Deposited Oxide

Article Preview

Abstract:

In this work, we propose and experimentally validate a novel approach to achieve superior interface properties of the SiO2/SiC MOS capacitors through a low-temperature oxide deposition technique for gate dielectric followed by a nitridation process. Low interface trap density (~ 5×1010 eV-1cm-2), robust flat-band voltage stability under positive bias stress, and decent leakage current density (JG ~ 5×10-10 A cm-2) can be unambiguously verified after nitric oxide (NO) gas post-deposition annealing.
