Fabrication and Testing of 6H-SiC JFETs for Prolonged 500 °C Operation in Air Ambient

Abstract:

This paper reports on the fabrication and testing of 6H-SiC junction field effect transistors (JFETs) and a simple differential amplifier integrated circuit that have demonstrated 2000 hours of electrical operation at 500 °C without degradation. The high-temperature ohmic contacts, dielectric passivation, and packaging technology that enabled such 500 °C durability are briefly described. Key JFET parameters of threshold voltage, on-state resistance, transconductance, and on-state current, as well as the gain of the differential amplifier integrated circuit, exhibited less than 7% change over the first 2000 hours of 500 °C operational testing.

• Periodical: Materials Science Forum (Volumes 600-603)
• Pages: 1079-1082
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.600-603.1079
• Online since: September 2008
• Authors: David J. Spry, Philip G. Neudeck, Liang Yu Chen, Glenn M. Beheim, Robert S. Okojie, Carl W. Chang, Roger D. Meredith, Terry L. Ferrier, Laura J. Evans
• Keywords: 6H-SiC, Amplifier, Differential Amplifier, Durability, High-Temperature, Junction Field Effect, Junction Field Effect Transistor (JFET), Packaging, Reliability, Transistor

References

[1] P. G. Neudeck, R. S. Okojie, and L.Y. Chen Proc. of IEEE, 90, p.1065 (2002).

[2] P. G. Neudeck et al.: Materials Sci. Forum 556-557, p.831 (2007).

[3] D. J. Spry, et al.: Proc. 2004 IMAPS Int. Conf. High Temperature Electronics, p. WA1.

[4] Cree Inc.: http: /www. cree. com.

[5] L. A. Lipkin, et al.: Journal of Electronic Materials 25, p.909 (1996).

[6] R. S. Okojie, et al.: Mat. Res. Soc. Symp. Proc. 622, p. H7. 5. 1 (2000).

[7] L. Y. Chen, et al.: Proc. 2006 IMAPS Int. Conf. High Temperature Electronics, p.240.
