Expansion of Stacking Faults by Electron-Beam Irradiation in 4H-SiC Diode Structure

Abstract:

The influence of electron-beam irradiation on defects in 4H-SiC diode structures was investigated by cathodoluminescence (CL) microscopy and spectroscopy. In addition to threading edge and screw dislocations, two types of stacking faults (SFs) were characterized by their emission energy, geometric shape, and the sensitivity of electron-beam irradiation. The SFs at λ = 425 nm (2.92 eV) expand from the surface of basal plane dislocation with line direction [11-20] and change their geometric shape by electron-beam irradiation. The SFs at λ = 471 nm (2.63 eV) are only slightly influenced by electron-beam irradiation. The former corresponds to the Shockley-type SFs previously observed in the degraded p-i-n diodes, and the latter to in-grown SFs with 8H structure. The panchromatic CL images constructed by the sum of monochromatic CL images suggest that there are nonradiative recombination centers in the vicinity of Shockley-type SFs. The nucleation sites and the driving force for SF expansion are discussed.

You might also be interested in these eBooks

Silicon Carbide and Related Materials 2007

View Preview

Info:

Periodical:

Materials Science Forum (Volumes 600-603)

Pages:

353-356

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.600-603.353

Citation:

Cite this paper

Online since:

September 2008

Authors:

Ryuichi Sugie, Masanobu Yoshikawa, Shin Harada, Yasuo Namikawa

Keywords:

4H-SiC, Cathodoluminescence, Diode, Recombination-Enhanced Dislocation Motion, Stacking Fault

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] M. Skowronski and S. Ha: J. Appl. Phys. Vol. 99, (2006), p.011101, and references therein.

Google Scholar

[2] J. J. Sumakeris, J. P. Bergman, M. K. Das, C. Hallin, B. A. Hull, E. Janzén, H. Lendenmann, M. J. O'Loughlin, M. J. Paisley, S. Ha, M. Skowronski: J. W. Palmour, and C.H. Carter Jr. Mater. Sci. Forum Vol. 527-529, (2006), p.141.

DOI: 10.4028/www.scientific.net/msf.527-529.141

Google Scholar

[3] S. Harada and Y. Namikawa: Mater. Sci. Forum Vol. 556-557, (2007), p.885.

Google Scholar

[4] K. Kanaya and S. Okayama: J. Phys. D: Appl. Phys. Vol. 5, (1972), p.43.

Google Scholar

[5] S. Harada, Y. Namikawa, and R. Sugie: submitted to this conference.

Google Scholar

[6] S. Izumi, H. Tsuchida, I. Kamata, and T. Tawara: Appl. Phys. Lett. Vol. 86, (2005), p.202108.

Google Scholar

[7] H. Fujiwara, T. Kimoto, T. Tojo, and H. Matsunami: Appl. Phys. Lett. Vol. 87, (2005), p.051912.

Google Scholar

[8] S. G. Sridhara, F. H. C. Carlsson, J. P. Bergman, and E. Janzén: Appl. Phys. Lett. Vol. 79, (2001), p.3944.

Google Scholar
