Growth of Cubic Silicon Carbide on Silicon Using Hot Filament CVD

Abstract:

In this paper, we report, for the first time, growth of high-quality single-crystalline 3C-SiC on silicon substrates using Hot Filament Chemical Vapor Deposition (HF-CVD). Rocking curve X-Ray diffraction (XRD) measurements revealed a full-width at half maximum (FWHM) as low as 333 arcsec for a 15 μm thick layer. Low tensile strain, below 0.1%, was measured using Raman spectroscopy. This quality was achieved with a carefully optimized process making use of the additional degrees of freedom the hot filaments create. For example, the hot filaments allow for precursor pre-cracking. Additionally, they allow a tuning of the vertical thermal gradient which creates an improved thermal field compared to classic Chemical Vapor Deposition techniques used for the deposition of this material today.

You might also be interested in these eBooks

Silicon Carbide and Related Materials 2016

View Preview

Info:

Periodical:

Materials Science Forum (Volume 897)

Pages:

91-94

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.897.91

Citation:

Cite this paper

Online since:

May 2017

Authors:

Philip Hens*, Ryan Brow, Hannah Robinson, Michael Cromar, Bart van Zeghbroeck

Keywords:

3C-SiC, Heteroepitaxy, Hot Filament CVD, RAMAN, X-Ray Diffraction

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] P.M. Sarro, Silicon carbide as a new MEMS technology, Sensors and Actuators 82 2000 210–218.

DOI: 10.1016/s0924-4247(99)00335-0

Google Scholar

[2] J. Komiyama et al., Stress reduction in epitaxial GaN films on Si using cubic SiC as intermediate layers, Journal of Applied Physics 100, 033519 (2006).

DOI: 10.1063/1.2226988

Google Scholar

[3] J. Wan et al., Inversion Channel MOSFETs in 3C-SiC on Silicon, Proceedings IEEE Lester Eastman Conference on High Performance Devices at University of Delaware, Newark, Delaware, August 6, 7, and 8. (2002).

DOI: 10.1109/lechpd.2002.1146735

Google Scholar

[4] A. Severino, 3C-SiC epitaxial growth on large area silicon: Thin films, Silicon Carbide Epitaxy, 2012: 145-191 ISBN: 978-81-308-0500-9 Editor: Francesco La Via.

Google Scholar

[5] Z. Zhang et al., Epitaxial monocrystalline SiC films grown on Si by HFCVD at 780°C, Materials Science and Engineering B75 (2000) 177-179.

DOI: 10.1016/s0921-5107(00)00357-3

Google Scholar

[6] K. Yasui et al., Low-Temperature Heteroepitaxial Growth of SiC on (100) Si Using Hot-Mesh Chemical Vapor Deposition, Japanese Journal of Applied Physics Vol. 44, No. 3 (2005), 1361–1364.

DOI: 10.1143/jjap.44.1361

Google Scholar

[7] J. Robbins and M. Seman, Production of bulk silicon carbide with hot-filament chemical vapor deposition, United States Patent # 8, 409, 351, Issued April 2, (2013).

Google Scholar
