Insight into Bias-Temperature Instability of SiC MOSFETs Using Charge Pumping and Triple-Sense Threshold Measurements

Abstract:

Bias-temperature instability (BTI) is one of the primary sources of parameter drift in silicon and SiC MOSFETs and consequently can determine device lifetime. Most studies of BTI in SiC MOSFETs have characterized the threshold voltage (V_T) but not the interface trap density (N_it), leaving uncertainty about the relative contributions of carrier capture and trap creation to the V_T shift. In this study, to lend insight into the physical mechanisms responsible for BTI in SiC MOSFETs, we measure N_it during positive bias-temperature stress (BTS) using the charge pumping (CP) technique. We also characterize the shift in V_T and hysteresis using the triple-sense method [1], [2] for comparison with the N_it changes to evaluate whether the changes in N_it are responsible for the V_T and/or hysteresis changes, and demonstrate the utility of the technique for reliable characterization of V_T and hysteresis in SiC MOSFETs.

• Periodical: Key Engineering Materials (Volume 1057)
• Pages: 35-41
• DOI: https://doi.org/10.4028/p-JdLnD2
• Online since: May 2026
• Authors: Shane R. Stein*, Suman Das, Daniel J. Lichtenwalner, Sei Hyung Ryu
• Keywords: Bias Temperature Instability, Border Traps, Charge Pumping, Hysteresis, Interface Traps, Threshold Voltage (V_th), Triple Sense Method
