Development of High-Voltage 4H-SiC GTOs for Grid-Tied Solar Inverters

Abstract:

A growing demand for smart and flexible photovoltaic power conversion and pulsed-power systems is leading to rapid development and commercialization of medium voltage 6.5 - 24 kV, wide-bang gap rectifiers and switches. Conventional silicon bipolar switches are limited to roughly 8 kV breakdown voltages and scaling up the voltage rating requires very thick wafers presenting significant manufacturing challenges. Very thick drift layers of silicon devices also translate into a very high minority carrier charge injected during forward conduction for an efficient conductivity modulation, hence leading to an extremely slow switching speed and poor efficiency. In this paper USCi presents the development of 6.5 kV 4H-SiC gate-turn-off thyristors (GTOs) with multiple floating guard-ring edge termination, and describes their application in an AC-link grid-tied solar inverter system.
