Impact of NO Annealing on Flatband Voltage Instability due to Charge Trapping in SiС MOS Devices

Abstract:

We evaluated the effect of NO annealing on hole trapping characteristic of SiC metal-oxide-semiconductor (MOS) capacitor by measuring flatband voltage (V_FB) shifts during a constant negative gate voltage stress under UV illumination. Under low stress voltages, the V_FBshift due to hole trapping was found to be suppressed by NO annealing. However, the V_FB shift of the NO-annealed device increases significantly with stress time under high stress voltage conditions, while the device without NO annealing showed only a slight shift. This result implies that NO annealing enhances generation of hole traps, leading to the degradation of SiC-MOS devices in long-term reliability.

You might also be interested in these eBooks

Silicon Carbide and Related Materials 2015

View Preview

Info:

Periodical:

Materials Science Forum (Volume 858)

Pages:

599-602

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.858.599

Citation:

Cite this paper

Online since:

May 2016

Authors:

Yoshihito Katsu*, Takuji Hosoi, Yuichiro Nanen, Tsunenobu Kimoto, Takayoshi Shimura, Heiji Watanabe

Keywords:

4H-SiC, Flatband Voltage, Hole Traps, MOS, Oxide Nitridation in NO, Post Oxidation Annealing (POA), Threshold Voltage Instability

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] H. –F. Li, S. Dimitrijev, H. B. Harrison and D. Sweatman, Interfacial characteristics of N2O and NO nitrided SiO2 grown on SiC by rapid thermal processing, Appl. Phys. Lett. 70 (1997) 2028-(2030).

DOI: 10.1063/1.118773

Google Scholar

[2] H. Yoshioka, T. Nakamura and T. Kimoto, Generation of very fast states by nitridation of the SiO2/SiC interface, J. Appl. Phys. 112 (2012) 024520.

DOI: 10.1063/1.4740068

Google Scholar

[3] H. Yoshioka, T. Nakamura, J. Senzaki, A. Shimozato, Y. Tanaka, H. Okumura and T. Kimoto, Accurate characterization of interface state density of SiC MOS structures and the impacts on channel mobility, Mater. Sci. Forum 778-780 (2014) 418-423.

DOI: 10.4028/www.scientific.net/msf.778-780.418

Google Scholar

[4] J. Rozen, S. Dhar, M. E. Zvanut, J. R. Williams and L. C. Feldman, Density of interface states, electron traps, and hole traps as a function of the nitrogen density in SiO2 on SiC, J. Appl. Phys. 105 (2009) 124506.

DOI: 10.1063/1.3131845

Google Scholar

[5] H. –F. Li, S. Dimitrijev and H. B. Harrison, Improved reliability of NO-nitrided SiO2 grown on p-type 4H-SiC, IEEE Electron Dev. Lett., 19 (1998) 279-281.

DOI: 10.1109/55.704399

Google Scholar

[6] D. Ikeguchi, T. Hosoi, Y. Nakano, T. Shimura and H. Watanabe, Insights into ultraviolet-induced electrical degradation of thermally grown SiO2/4H-SiC(0001) interface, Appl. Phys. Lett. 104 (2014) 012107.

DOI: 10.1063/1.4860987

Google Scholar
