4600 V Sic Dmosfets with R_DS,On = 17 mΩ-cm²

Abstract:

Large-area, 7.84 mm² SiC DMOSFETs feature breakdown voltages of 4600 V, specific on-resistance of 17 mΩ-cm² and gate threshold voltage of 2.4 V. The low on-resistance was enabled by an optimized MOS process that resulted in channel mobility as high as 27 cm²/Vs, and oxide breakdown fields in the 10-11 MV/cm range. The key device design and layout parameters were varied to examine the performance versus reliability trade-offs.
