Fabrication of the Planar SiC Gate-all-Around JFET with Channel Dose Modulation

Abstract:

Currently, silicon carbide (SiC) is widely recognized as a wide bandgap semiconductor, with expanding applications in harsh environments, such as high temperature and radiation exposure. In this study, we fabricated a planar structure 4H-SiC gate-all-around junction field-effect transistor (JFET), wherein the channel region is formed through ion implantation at varying doses. We successfully produced both normally-on and normally-off JFETs. Moreover, we constructed a JFET commonsource amplifier. The amplifiers achieved a maximum gain of -226.7 (47.1 dB) at a supply voltage of V_DD = 30 V.

By email View Pdf

You have full access to the following eBook

Technological Improvements in Devices Fabrication

Read eBook

Info:

Periodical:

Materials Science Forum (Volume 1159)

Pages:

67-72

DOI:

https://doi.org/10.4028/p-xm5gzM

Citation:

Cite this paper

Online since:

September 2025

Authors:

Takanori Amamiya, Masayuki Yamamoto*, Hitoshi Umezawa, Koji Nakayama, Takeharu Kuroiwa, Shinichiro Kuroki, Yasunori Tanaka

Keywords:

Common-Source Amplifier, Gate-all-Around (GAA), Harsh Environment, JFET, Silicon Carbide (SiC)

Export:

RIS, BibTeX

Permissions:

Creative Commons CC BY 4.0
